FIREWARM INSET STOVE
5kW Nominal Output
FW5C
Installation and Operating
Instructions
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
Heat Design
30 – 60 Hawthorn Road
Western Industrial Estate
Naas Road
Dublin 12
www.heatdesign.ie
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
For safety reasons it is essential that your stove is correctly installed and operated. Firewarm Stoves
cannot accept responsibility for any fault or consequential problems arising through incorrect
installation or operation.
Advertisement
Table of Contents
Related Manuals for Heat Design FW5C
Summary of Contents for Heat Design FW5C
- Page 1 FIREWARM INSET STOVE 5kW Nominal Output FW5C Installation and Operating Instructions Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for operation and instruct the user in the correct use of the appliance and operation of controls.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page No 1. List of Components 2. Component Identification and Assembly 3. Installation Instructions 3.1 Warnings and important safety information 4 Installation Information 4.1 Chimney 4.2 Ventilation 4.3 Flue Draught 4.4 Connection to Chimney 4.5 Material Clearances 4.6 Fixing 4.7 Hearths 4.8 Commissioning &... -
Page 3: List Of Components
Stove Operating Glove Touch up paint Warranty Card Fig 2 – FW5C Stove Assembly and controls 2. Component Identification and Assembly Your Firewarm Cassette Stove comes packed in a cardboard box. Carefully remove any straps and remove all cardboard and any plastic packaging, open the door and remove all the contents. See List of Components section and check contents carefully. -
Page 4: Installation Instructions
3 Installation Instructions WARNINGS AND IMPORTANT SAFETY INFORMATION 3.1.1 READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION! These instructions cover the basic principles to ensure satisfactory installation of the stove, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current local regulations including Building Regulations, Local Authority Byelaws and other specifications or regulations including Ireland, UK or EU standards referred to as they affect the installation of the stove. -
Page 5: Installation Information
3.1.10 Asbestos This stove contains no asbestos. If there is a possibility of disturbing any asbestos in the course of installation then please seek specialist guidance and use appropriate protective equipment. 3.1.11 Metal Parts When installing or servicing this stove, proper care should be taken to avoid the possibility of personal injury. -
Page 6: Material Clearances
4.7 Hearths: The FW5C stove require a 125mm thick non-combustible constructional hearth beneath them to protect the building, this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided. The superimposed hearth must not be less than 12mm thick and must have a clearly defined edge (change of level) to discourage placing of any combustible materials on or partially over it. -
Page 7: Technical Data
Advise the user on what to do should smoke or fumes be emitted into the room from the stove – see Safety Notes section. The user should be warned that they MUST use a suitable fireguard in the presence of children, aged and/or infirm persons. 5.0 Technical Data Model FW5C 66.5 Appliance weight (Kg): Efficiency (%) on Wood fuel 80.4... -
Page 8: Cleaning
Tertiary Air This appliance is also fitted with a preheated tertiary air system controlled via a sliding control located on the bottom left of the stove just below the door (same as secondary air). Moving towards the wide side of the arrow increases the tertiary air supply whilst moving towards the narrow side reduces it. -
Page 9: Lighting The Stove
See also: section entitled ‘Lighting the Stove’. Wood burns best on a bed of ash and it is therefore only necessary to remove surplus ash from the stove occasionally. If the grate is completely clear, place a few handfuls of ash into the slots in the grate to help the firebed build up. -
Page 10: Shutting Down
6.7 Shutting Down The stove will normally shut down by itself as the fuel is consumed. In order to shut down the stove for other reasons, close the primary air controls (if open), then close the secondary air control. If the controls are left in this position, the fire will eventually burn out. - Page 11 Fig. 3 – FW5C Cassette Stove Dimensions HD02 01/10/11...
-
Page 12: Frequently Asked Questions
Frequently Asked Questions 1 Do stoves require a chimney? All of our multi fuel and wood burning stoves require a suitable chimney or professionally installed flue system. 2 How do I clean the chimney? You will require a chimney sweep to clean the chimney. It is essential to provide a dedicated chimney cleaning access door when installing the flue of the stove in some situations. - Page 13 Heat Design, 30 – 60 Hawthorn Road, Western Industrial Estate, Naas Road, Dublin 12 T: 01 408 9192 F: 01 408 9193 HD02 01/10/11...
