GREEN
GR6i
INSERT STOVE
Please fix label with serial number and stove
Type here before putting manual into stove
Installation and Operating
Instructions
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
Advertisement
Table of Contents
Related Manuals for Heat Design GREEN GR6i
Summary of Contents for Heat Design GREEN GR6i
- Page 1 GREEN GR6i INSERT STOVE Please fix label with serial number and stove Type here before putting manual into stove Installation and Operating Instructions Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for operation and instruct the user in the correct use of the appliance and operation of controls.
- Page 2 Heat Design 30 – 60 Hawthorn Road Western Industrial Estate Naas Road Dublin 12 www.heatdesign.ie PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Hothouse cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Page No 1. List of Components 2. Component Identification and Installation 3. Installation Instructions Warnings and important safety information 4 Installation Information Chimney Ventilation Flue Draught Connection to Chimney Material Clearances Hearths Commissioning & Handover 5. Technical Data 6. -
Page 4: List Of Components
Fig 1 – Stove Tool 1. List of Components Description of Parts GR6ii Stove Assembly Tool Ash Pan Fixing bar Bag containing fixings Stove Operating Glove Touch up paint Spare rope Warranty Card Fig 2 – GR6i Stove Assembly and controls 2. -
Page 5: Installation Instructions
Secure the fixing bar and the tightening screw to the stove as shown in fig. 2. Do not put on the wingnut until the stove is in place. Place the insert stove into position and mark the intended position of the fixing screw in the fireplace through the hole in the base of the appliance. -
Page 6: Installation Information
Ventilation No purpose provided ventilation is normally required for stoves rated under 5KW. However for newer build properties or properties that have been modified so that the design air permeability is less than /h.m a permanent ventilator will need to be fitted. Approved document J of the building Regulations gives more detailed information. -
Page 7: Connection To Chimney
Hearths: Heat Design stoves require a 125mm thick non-combustible constructional hearth beneath them to protect the building, this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided. -
Page 8: Technical Data
On completion of the installation and commissioning, ensure that the operating instructions and operating tools (including glove) for the stove are left with the customer. You must be sure to advise the customer on the correct use of the appliance with the fuels likely to be used on the stove and warn them to use only the recommended fuels for the stove. -
Page 9: Cleaning
very low. The primary air inlet will usually be closed when burning wood and open when burning coal type fuel. Secondary Air (Air Wash) The GR6i stove has a powerful “air wash” system. This secondary air supply to the stove is controlled via a rotating dial control located on the top right of the stove. -
Page 10: Notes On Burning Solid Fuel
With a full load of wood, the stove will need to be refuelled approximately every 0.75 hours depending on burn rate. Wood can be stacked in the stove but care must be taken that logs do not touch the baffle. Do not stack fuel above the level of the tertiary air inlets at the back of the stove. -
Page 11: Fuel Overloading
fuel charge will ignite in a reasonable period. If there are too few embers in the fire bed, add suitable kindling to prevent excessive smoke Fuel Overloading Four good size logs is a sufficient quantity of fuel to achieve the rated output from this appliance. Never exceed this amount of fuel and never stack the fuel too high in the stove so as it touches the baffle or blocks the tertiary air holes as this may cause smoke to be produced. -
Page 12: Stove Dimensions
WARNING NOTE – FUME EMISSION Properly installed, operated and maintained this appliance will not emit fumes into the dwelling. Occasional fumes from de-ashing and refuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, then the following immediate action should be taken: - Open doors and windows to ventilate room and then leave the premises Let the fire out Check for flue or chimney blockage and clean if required... -
Page 13: Frequently Asked Questions
3 Who should install my stove? Heat Design want you to enjoy the maximum performance from your appliance. To ensure this, it is essential that they are installed correctly. We strongly recommend that your stove is installed by a suitably qualified installer e.g HETAS. - Page 14 A call out charge will apply if our engineer attends any stove problem that is not related to product failure. 6 Where can I get spare parts? Your local Heat Design Stove retailer will be pleased to supply spare parts and to provide any other information you require.
- Page 15 10.0 GR6i Spare Parts List & Codes Component GR6i Component GR6i Door Glass Y1HDI04D01E Ashpan Y1HDID28E Glass Brackets and Screws Y1HDID02E Glove Y1HD29E Door Handle assembly Y1GRI03D03E Ashpan Tool Y1HD31E Coalcatcher Y1GRI05D04E Door Y1GRI05D32F Back Plate/fireboard Y1HDI04D05E Y1GRF06D33A Primary / Secondary Air Control Side Plate Left/fireboard Y1HDI04D06E Front...
- Page 16 GR6i 28/12/13...
- Page 17 GR6i 28/12/13...
- Page 18 Heat Design 30 – 60 Hawthorn Road Western Industrial Estate Naas Road Dublin 12 www.heatdesign.ie GR6i 28/12/13...
