The FW4SE, FW6SE and FW8SE have been exempted under the clean air act of 1993 as suitable for use in
smoke control areas when burning seasoned wood logs. The stove contains a factory fitted secondary air
stop which ensures that the secondary air is permanently open 4-9mm minimum. Please carefully read the
instructions on wood burning contained in this manual, these MUST be adhered to at all times. Please see
page 16 of the manual for further reference to the clean air act of 1993
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
For safety reasons it is essential that your stove is correctly installed and operated. Heat Design
cannot accept responsibility for any fault or consequential problems arising through incorrect
installation or operation.
These appliances have been approved by HETAS Ltd as intermittent operating appliances for
FW4SE, FW6SE& FW8SE
SMOKE EXEMPT
FREESTANDING STOVE
Installation and Operating
Instructions
Please affix the serial number here
before putting the manual in the stove
Heat Design Ltd.
30-60 Hawthorn Road
Western Industrial Estate,
burning wood logs only
Naas Road,
Dublin 12
www.heatdesign.ie
Advertisement
Table of Contents
Related Manuals for Heat Design FW4SE
Summary of Contents for Heat Design FW4SE
- Page 1 The FW4SE, FW6SE and FW8SE have been exempted under the clean air act of 1993 as suitable for use in smoke control areas when burning seasoned wood logs. The stove contains a factory fitted secondary air stop which ensures that the secondary air is permanently open 4-9mm minimum.
-
Page 2: Table Of Contents
Re-fuelling Slow Burning Maintenance 7. Safety Notes for your Guidance 8. Stove Dimensions 9. Frequently Asked Questions 10. Spare Parts List & Codes FW4SE 11. Spare Parts List & Codes FW6SE 12. Spare Parts List & Codes FW8SE FW468SE 27-06-13... -
Page 3: List Of Components
Stove Assembly Tool Ash Pan Flue Collar Flue Collarfixing screws & Washers Legs Stove Operating Glove Touch up paint Warranty Card Fig 2 – FW4SE Stove Assembly and controls Fig 3 – FW6SE and FW8SE Stove Assembly and controls FW468SE 27-06-13... -
Page 4: Component Identification And Assembly
2. Component Identification and Assembly Your Firewarm Stove comes packed in a cardboard box/crate. Carefully remove any straps and remove all cardboard and any plastic or wooden packaging, open the door and remove all the contents. See List of Components section and check contents carefully. Remove the coal catcher by lifting it up and rotating it until it can be removed through the open door of the stove Now lift up the baffle plate and rotate it and remove from the stove, long side first. -
Page 5: Installation Information
build up of soot or debris on the top from the flue pipe. Remove the baffle and check the flue spigot and connector is fully clear at regular intervals. The chimney and flue connector must be swept at least annually, more often when used with sooty fuels or damp wood. -
Page 6: Flue Draught
If the problem persists seek the advice of a chimney sweep. Material Clearances Safety Distances from Combustible Surfaces: Model Side Rear FW4SE 500mm 700mm FW6SE 400mm 400mm FW8SE... -
Page 7: Commissioning & Handover
Notes section. The user should be warned that they MUST use a suitable fireguard in the presence of children, aged and/or infirm persons. CO Alarm – Please ensure a CO alarm has been fitted as detailed on page 9 of these instructions 5.0 Technical Data Technical Specifications (Wood) FW4SE FW6SE FW8SE Nominal Heat Output Efficiency 76.6... -
Page 8: Operating Instructions
6.0 Operating Instructions This appliance is not designed for open operation and therefore should not be operated with the doors open, this could cause excessive smoke and could also harm the appliance. This stove is designed to burn cleanly with high efficiency. If used correctly this stove will burn with the very useful feature of clean glass. -
Page 9: Fuels
mean that the paint does not have much effect before being burnt off. Steel and cast iron liners are resilient firebox materials and will give reliable service without major cleaning or work on the firebox. Baffle: It is essential to check the top of the baffle for build-up of soot and ash regularly when in use and after a long period of no use. -
Page 10: Slow Burning
burn for a few minutes until the fire is well established before closing the secondary air once again. This refuelling procedure will ensure that smoke emission is kept to a minimum. Do not operate the appliance with the air controls fully open for a prolonged period as it will cause over firing and may result in smoke being produced. -
Page 11: Stove Dimensions
8.0 Stove Dimensions All dimensions in mm unless otherwise stated. Dimensions are approximate and are subject to change without prior notice. Fig. 4 – FW Stove Dimensions Stove FW4SE 5” FW6SE 5” FW8SE 6” FW468SE 27-06-13... -
Page 12: Frequently Asked Questions
Frequently Asked Questions 1 Do stoves require a chimney? All of our multi fuel and wood burning stoves require a suitable chimney or professionally installed flue system. 2 How do I clean the chimney? You will require a chimney sweep to clean the chimney. It is essential to provide a dedicated chimney cleaning access door when installing the flue of the stove in some situations. -
Page 13: Spare Parts List & Codes Fw4Se
10.0 – Spare Parts FW4SE Component FW4SE Component FW4SE Door Glass Y1HDF04D01E Ashpan Y1HDF04D28E Glass Brackets and Screws Y1HDF04D02E Glove Y1HD29E Door Handle assembly Y1FWF04D03E Ashpan Tool Y1HD31E Coalcatcher Y1FWF04D04E Door Y1FWF04D32E Back Plate/fireboard Y1HDF04D05E Primary Air Control including handle... -
Page 14: Spare Parts List & Codes Fw6Se
11.0 – Spare Parts FW6SE Component FW6SE Component FW6SE Door Glass Y1HDF06D01E Collar Y1HD23E Glass Brackets and Screws Y1HDF06D02E Ashpan Y1HDF06D28E Door Handle assembly Y1FWF06D03E Glove Y1HD29E Coalcatcher Y1FWF06D04E Ashpan Tool Y1HD31E Back Plate/fireboard Y1HDF06D05E Door Y1FWF06D32E Side Plate Left/fireboard Y1HDF06D06E Primary Air Control including handle Y1FWF06D33E... -
Page 15: Spare Parts List & Codes Fw8Se
12.0 – Spare Parts FW8SE Component FW8SE Component FW8SE Door Glass Y1HDF08D01E Collar Y1HD24E Glass Brackets and Screws Y1HDF08D02E Ashpan Y1HDF08D28E Door Handle assembly Y1FWF08D03E Glove Y1HD29E Coalcatcher Y1FWF08D04E Ashpan Tool Y1HD31E Back Plate/fireboard Y1HDF08D05E Door Y1FWF08D32E Side Plate Left/fireboard Y1HDF08D06E Primary Air Control including handle Y1FWF08D33E... - Page 16 Your local authority is responsible for implementing the Clean Air Act 1993 including designation and supervision of smoke control areas and you can contact them for details of Clean Air Act requirements” Heat Design, 30-60 Hawthorn Road, Western Industrial Estate, Naas Road, Dublin 12. T:01 408 9192 F:01 408 9193...
