FIREWARM CASETTE STOVE
The VIT11C stove has been exempted under the clean air act of 1993 as suitable for use in smoke
control areas when burning seasoned wood logs. The stove contains a factory fitted secondary
air stop which ensures that the secondary air is permanently open 5mm minimum. Please
carefully read the instructions on wood burning contained in this manual, these MUST be adhered
to at all times. Please see page 15 of the manual for further reference to the clean air act of 1993
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
For safety reasons it is essential that your stove is correctly installed and operated. Firewarm Stoves
cannot accept responsibility for any fault or consequential problems arising through incorrect
installation or operation.
10.7kW Nominal Output
Installation and Operating
Instructions
Please fix label with serial number of stove
before putting manual into stove
30 – 60 Hawthorn Road
Western Industrial Estate
www.heatdesign.ie
FW11C
Heat Design
Naas Road
Dublin 12
Advertisement
Table of Contents
Related Manuals for Heat Design FW11C
Summary of Contents for Heat Design FW11C
- Page 1 FIREWARM CASETTE STOVE 10.7kW Nominal Output FW11C Installation and Operating Instructions Please fix label with serial number of stove before putting manual into stove The VIT11C stove has been exempted under the clean air act of 1993 as suitable for use in smoke control areas when burning seasoned wood logs.
-
Page 2: Table Of Contents
6.4 Notes on Wood Burning 6.5 Notes in burning Solid Fuel 6.6 Lighting the stove 6.7 Re-fuelling 6.8 Shutting down 6.9 Maintenance 6.10 Seasonal Use 7. Safety Notes for your Guidance 8. Frequently Asked Questions 9. Spare Parts List & Codes FW11C 18-12-12... -
Page 3: List Of Components
Stove Operating Glove Touch up paint Warranty Card Fig 2 – FW11C Stove Assembly and controls 2. Component Identification and Assembly Your Firewarm Cassette Stove is shipped securely packed and strapped. Carefully remove any straps and remove all wood, cardboard and any plastic packaging, open the door and remove all the contents. -
Page 4: Stove Commissioning Checklist
Retailer from whom the appliance was purchased Name: ………………………………………………………………………….. Address: ………………………………………………………………………… …………………………………………………………………………………… Telephone Number: ……………………………………………………………... Complete upon stove installation Date of Installation: …………………………………………………… Model Number: FW11C Serial Number: ………………………………………………………… Fitter/Plumber Name: ………………………………………………………………….. Address: ………………………………………………………………... Telephone Number: ……………………………………………………. Commissioning Checklist – Installer to complete and sign-off... -
Page 5: Warnings And Important Safety Information
Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. In case of skin contact, wash immediately with plenty of water. FW11C 18-12-12... -
Page 6: Site Requirements
In addition it is strongly recommended that any furniture or other combustible materials are kept at least 1000mm clear from the front of the stove and any mantle is at least 300mm above the stove. FW11C 18-12-12... -
Page 7: Fitting The Stove
Hearths: The FW11C stove require a 125mm thick non-combustible constructional hearth beneath them to protect the building, this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided. The superimposed hearth must not be less than 12mm thick and must have a clearly defined edge (change of level) to discourage placing of any combustible materials on or partially over it. - Page 8 Advise the user on what to do should smoke or fumes be emitted into the room from the stove – see Safety Notes section. The user should be warned that they MUST use a suitable fireguard in the presence of children, aged and/or infirm persons. FW11C 18-12-12...
-
Page 9: Technical Data
Seasoned wood with moisture Wood content less than 20% Recommended fuel Manufactured Smokeless coal Solid Fuel suitable for closed appliances Appliance tested to the requirement of standard EN13229 : 2001 / A2 : 2004 *Average reading at nominal output FW11C 18-12-12... -
Page 10: Operating Instructions
Replace the empty ashpan in the stove making sure to push it fully into place so that all the ash falls into it. DO NOT allow ash to build up underneath the bed as this may cause damage to the grate. Never operate the stove without the ashpan in place. FW11C 18-12-12... -
Page 11: Cleaning
See section 6.6 on lighting the stove. After the fire has become established close the airwash until it is approximately 25% open and use the primary air control to set the burn rate. De-ash the stove by riddling a FW11C 18-12-12... -
Page 12: Lighting The Stove
The fire will then often need reviving by first de-ashing and then using small pieces of wood and plenty of air to get flames issuing from the wood again. FW11C 18-12-12... -
Page 13: Shutting Down
Let the fire out, or remove and safely dispose of fuel from the appliance. Check for flue chimney blockage and clean if required. Do not attempt to re-light the fire until the cause has been identified and corrected. FW11C 18-12-12... -
Page 14: Frequently Asked Questions
If any part of stove glows "red" your stove is over firing and your draught control should be adjusted to restrict airflow to stove. Over firing can cause permanent damage to the appliance, which is not covered by warranty. FW11C 18-12-12... -
Page 15: Spare Parts List & Codes
FW11C 18-12-12... - Page 16 9. FW11C – Spare Parts and codes Component FW11C Component FW11C Door Glass Y1HDC11D01A Primary Air Control including handle Y1HDC06D33B Glass Brackets and Screws Y1HDC11D02A Outer skin for Insert/Casette Y1HDC11D43A Door Handle assembly Y1HDC11D03A Inner Skin for Insert/Cassette Y1HDC11D44B Coalcatcher...
- Page 17 Clean Air Act requirements” Heat Design, 30 – 60 Hawthorn Road, Western Industrial Estate, Naas Road, Dublin 12 T: 01 408 9192 F: 01 408 9193...
