The TR7i stove has been exempted under the clean air act of 1993 as suitable for use in smoke control areas when
burning seasoned wood logs. The stove contains a factory fitted secondary air stop which ensures that the
secondary air is permanently open 3.5mm minimum. Please carefully read the instructions on wood burning
contained in this manual, these MUST be adhered to at all times. Please see page 15 of the manual for further
reference to the clean air act of 1993
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
For safety reasons it is essential that your stove is correctly installed and operated. Heat Design
cannot accept responsibility for any fault or consequential problems arising through incorrect
installation or operation.
TR Range
INSERT STOVE
Please fix label with serial number and stove
type here before putting manual into stove
Installation and Operating
Instructions
Heat Design Ltd.
Western Industrial Estate,
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
TR7i
30-60 Hawthorn Road
Naas Road,
Dublin 12
www.heatdesign.ie
Advertisement
Table of Contents
Related Manuals for Heat Design TR Series
Summary of Contents for Heat Design TR Series
- Page 1 Dublin 12 www.heatdesign.ie PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Heat Design cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page No 1. List of Components 2. Component Identification and Installation 3. Installation Instructions Warnings and important safety information 4 Installation Information Chimney Ventilation Flue Draught Connection to Chimney Material Clearances Hearths Commissioning & Handover 5. Technical Data 6. -
Page 3: List Of Components
Fig 2 – TR7i Stove Assembly and controls 2. Component Identification and Installation Your Heat Design Stove comes packed in a cardboard box. Carefully remove any straps and remove all cardboard and any plastic packaging, open the door and remove all the contents. See List of Components section and check contents carefully. -
Page 4: Installation Instructions
• Create a seal with the fascia of the fireplace. Place hand through the stove flue collar and tighten the wingnut onto the tightening bar. The fixing bar creates pressure when it contacts the chimney/lintel. The stove should be tightly sealed to the fireplace fascia. •... -
Page 5: Installation Information
Keep all ventilation clear and free of blockage. Health And Safety Precautions Handling Adequate facilities must be available for unloading and site handling. Heat Design Stoves are very heavily built so always ask for assistance when lifting and siting the stoves. Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 6: Connection To Chimney
Hearths: Heat Design stoves require a 125mm thick non-combustible constructional hearth beneath them to protect the building, this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided. -
Page 7: Technical Data
the correct use of the appliance with the fuels likely to be used on the stove and warn them to use only the recommended fuels for the stove. Advise the user on what to do should smoke or fumes be emitted into the room from the stove – see Safety Notes section. -
Page 8: Cleaning
Tertiary Air This appliance is also fitted with a preheated tertiary air system which burns otherwise uncombusted gases in the products of combustion thereby improving efficiency, increasing heat output and decreasing unwanted atmospheric emissions. At certain stages of burning you will notice “jets” of flame emerging near the air holes to the rear of the firebox. -
Page 9: Fuels
Fuels The appliance is fitted with a versatile multifuel grate and has been tested using wood and coal. Notes on Wood burning With a full load of wood, the stove will need to be refuelled approximately every 1 to 1.5 hours depending on burn rate. -
Page 10: Refuelling Onto A Low Firebed
by first de-ashing and then using small pieces of wood and plenty of air to get flames issuing from the wood again. Refuelling on to a low fire bed If there is insufficient burning material in the fire bed to light a new fuel charge, excessive smoke emission can occur. -
Page 11: Safety Notes For Your Guidance
7.0 Safety Notes for your guidance FIRES CAN BE DANGEROUS – Always use a fireguard in the presence of children, the elderly or the infirm. DO NOT perform modifications to the appliance as this could seriously compromise safety in operation. DO NOT OVERFIRE –... -
Page 12: Stove Dimensions
8.0 Stove Dimensions Fig. 3 – TR7i Insert Stove All dimensions in mm unless otherwise stated. Dimensions are approximate and are subject to change without prior notice. TR7I 23/07/14... - Page 13 TR7I 23/07/14...
-
Page 14: Frequently Asked Questions
A call out charge will apply if our engineer attends any stove problem that is not related to product failure. 6 Where can I get spare parts? Your local Heat Design Stove retailer will be pleased to supply spare parts and to provide any other information you require. -
Page 15: Tr7I Spare Parts List & Codes
10.0 TR7i Spare Parts List & Codes Component TR7i Component TR7i Door Glass Y1HDI04D01E Ashpan Y1HDI07D28E Glass Brackets and Screws Y1HDID02E Glove Y1HD29E Door Handle assembly Y1TRI04D03E Ashpan Tool Y1HD31E Coalcatcher Y1TRI04D04E Door Y1TRI04D32E Back Plate/fireboard Y1HDI07D05E Primary Air Control including handle Y1TRF08D33E Side Plate Left/fireboard Y1HDI07D06A... - Page 16 TR7I 23/07/14...
- Page 17 Heat Design, 30-60 Hawthorn Road, Western Industrial Estate, Naas Road, Dublin 12. T: 01 408 9192 F: 01 408 9193 TR7I 23/07/14...
