SAN REMO
STEEL STOVE
RANGE
Installation and Operating
Instructions
Please fix label with serial number of stove
before putting manual into stove
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
Heat Design
30 – 60 Hawthorn Road
Western Industrial Estate
Naas Road
Dublin 12
www.heatdesign.ie
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
For safety reasons it is essential that your stove is correctly installed and operated. Heat Design
cannot accept responsibility for any fault or consequential problems arising through incorrect
installation or operation.
Advertisement
Table of Contents
Related Manuals for Heat Design SR 5 S
Summary of Contents for Heat Design SR 5 S
- Page 1 Dublin 12 www.heatdesign.ie PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Heat Design cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page No 1. List of Components 2. Component Identification and Assembly 3. Stove Commissioning Checklist 3. Installation Instructions 3.1 Warnings and important safety information 4 Installation Information 4.1 Chimney Information 4.2 Flue Draught Requirements 4.3 Connection to the Chimney 4.4 Fitting the Stove 5. -
Page 3: List Of Components
Fig 1 – Ashpan Tool 1. List of Components Description of Parts San Remo Stove Assembly Stove Tool Ash Pan Instruction Manual Lower Baffle Upper Baffle Stove Operating Glove Warranty Card Fig 2 – Stove Assembly and controls 2. Component Identification and Assembly Your San Remo Steel Stove is shipped securely packed and strapped. -
Page 4: Stove Commissioning Checklist
Name: ………………………………………………………………………….. Address: ………………………………………………………………………… …………………………………………………………………………………… Telephone Number: ……………………………………………………………... Complete upon stove installation Date of Installation: …………………………………………………… Model Number: (SR 5 S or SR 5 SW or SR 8 S) …………………... Serial Number: ………………………………………………………… Fitter/Plumber Name: ………………………………………………………………….. Address: ………………………………………………………………... Telephone Number: ……………………………………………………. -
Page 5: Installation Instructions
Handling Adequate facilities must be available for unloading and site handling. Heat Design Stoves are very heavily built so always ask for assistance when lifting and siting the stoves. Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 6: Installation Information
Ventilation Any Room or space containing an appliance should have permanent ventilation opening of free area of 550mm sq per kw of rated output but in no case less than 6500mm sq where air permeability is greater than 5.0m3, or 6500mmsq +550mmsq per kw of rated output above 5 Kw where the air permeability is less than 5.0m3. -
Page 7: Fitting The Stove
If the problem persists, seek the advice of a chimney sweep. Material Clearances Safety Distances from Combustible Surfaces: Model Back Side Floor SR 5 S 400mm 550mm 500mm SR 5 SW 500mm 600mm... -
Page 8: Technical Data
Commissioning and Handover Upon completion of the installation, allow a suitable period of time for any fire cement and mortar to dry out. A small fire may then be lit and checked to ensure the smoke and fumes are taken from the stove up the chimney and emitted safely to the atmosphere. - Page 9 Stove Dimensions San Remo 5 S San Remo 5 SW San Remo 8 S SR Steel 12-7-2023...
-
Page 10: Operating Instructions
6 Operating Instructions This appliance is not designed for open operation and therefore should not be operated with the doors open. This stove is designed to burn cleanly with high efficiency. When used correctly this stove will burn very efficiently and cleanly with the very useful feature of clean glass. However, for this product to work properly it must be used correctly. -
Page 11: Cleaning
6.2 Cleaning Glass: Despite the advanced air wash system provided, the glass will still need cleaning from time to time depending on the fuel quality and burning rates used. Never clean glass when the stove is hot. Always use stove glass cleaner or ceramic hob cleaner, which is available from your stove retailer. As an alternative, use a wet cloth with some of the wood ash if burning wood but be very careful to use very clean ash so as not to scratch the glass. -
Page 12: Notes On Solid Fuel Burning
6.5 Notes on Burning Solid Fuel After the fire has become established close the airwash until it is approximately 25% open and use the primary air control to set the burn rate. De-ash the stove with a poker a few times before adding new fuel. Open the primary air 100% for a few minutes before refuelling to establish a good hot bed. -
Page 13: Maintenance
Clean Air Act requirements. Heat Design smoke control stoves must not be operated with the controls and door left open as this will cause excess smoke being emitted into the atmosphere. -
Page 14: Safety Notes For Your Guidance
7.0 Safety Notes for your guidance FIRES CAN BE DANGEROUS – Always use a fireguard in the presence of children, the elderly or the infirm. DO NOT OVERFIRE – it is possible to fire the stove beyond its design capacity, this could damage the stove, so watch for signs of overfiring –... -
Page 15: Frequently Asked Questions
8 Frequently Asked Questions 1 Do stoves require a chimney? All of our multi fuel and wood burning stoves require a suitable chimney or professionally installed flue system. 2 How do I clean the chimney? You will require a chimney sweep to clean the chimney. It is essential to provide a dedicated chimney cleaning access door when installing the flue of the stove in some situations. - Page 16 9. SPARE PARTS LISTS & CODES San Remo Steel 5 S Component San Remo 5 S Component San Remo 5 S Door Glass Y1SRSTF05SD01A Primary Air Control handle Y1SRSTF05SD27A Glass Brackets and Screws Y1SRSTF05SD02A Collar Blanking Plate Y1SRSTF05SD33A Door Handle assembly Y1SRSTF05SD03A Tertiary Air box Y1SRSTF05SD40A...
-
Page 17: San Remo 5 Sw
10. SPARE PARTS LISTS & CODES San Remo Steel 5 SW Component San Remo 5 SW Component San Remo 5 SW Door Glass Y1SRSTF05SWD01A Primary Air Control handle Y1SRSTF05SWD27A Glass Brackets and Screws Y1SRSTF05SD02A Collar Blanking Plate Y1SRSTF05SD33A Door Handle assembly Y1SRSTF05SD03A Tertiary Air box Y1SRSTF05SWD40A... -
Page 18: San Remo 8 S
11. SPARE PARTS LISTS & CODES San Remo Steel 8 S Component San Remo 8 S Component San Remo 8 S Door Glass Y1SRSTF08SD01A Primary Air Control handle Y1SRSTF05SWD27A Glass Brackets and Screws Y1SRSTF05SD02A Collar Blanking Plate Y1SRSTF05SD33A Door Handle assembly Y1SRSTF05SD03A Tertiary Air box Y1SRSTF08SD40A... - Page 19 GLASS IS NOT COVERED UNDER WARRANTY Heat Design, 30 – 60 Hawthorn Road, Western Industrial Estate, Naas Road, Dublin 12 T: 01 408 9192 F: 01 408 9193...
