3.8 Email Settings

An XPort can send an email to multiple recipients when a specific trigger event occurs. There are three
separate triggers, based on any combination of the configurable pins selected as user I/O functions.
Optionally, use a two-byte serial string to initiate a trigger. Each trigger is independent of the others. Each
condition within an individual trigger must be met before the unit will send the email.
Note: Using configurable pins for Email is not supported on the NET485.
To configure the NET232's email settings:
1. On the main menu, select Email. The Email Settings window opens.
2. Configure the following fields:
Server IP Address
Server Port
Domain Name
Unit Name
Recipients
Recipient 1: Email
Address
Recipient 2: Email
Address
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
3-18
Enter the IP address of the mail server.
Enter the port number on the email server.
Enter the email server's domain name.
Enter the user name used by the XPort to send email messages.
Enter the email address designated to receive email notifications
Enter an additional email address designated to receive email
notifications.
NET485 User Guide
