3.5 Server Configuration

The unit's server values display when you select Server from the main menu. The following sections describe
the configurable parameters on the Server Settings page.
To configure the XPort's device server settings:
1. On the main menu, click Server.
2. Configure or modify the following fields:
Server Configuration
Telnet Password
Retype Password
Advanced
ARP Cache Timeout
TCP Keepalive
Monitor Mode @ Bootup Select Disable to disable entry into the monitor mode using the 'yyy' or 'xx1'
CPU Performance Mode Select the XPort's performance mode. Higher performance settings require
HTTP Server Port
MTU Size
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
3-10
Enter the password required for Telnet access
Re-enter the password required for Telnet access.
When the unit communicates with another device on the network, it adds
an entry into its ARP table. ARP Cache timeout defines the number of
seconds (1-600) before it refreshes this table.
TCP Keepalive time defines how many seconds the unit waits during an
inactive connection before checking its status. If the unit does not receive a
response, it drops that connection. Enter a value between 0 and 60
seconds. 0 disables keepalive.
key sequence at startup. This field prevents the unit from entering monitor
mode by interpreting the stream of characters that are received during the
device server's initialization at startup.
more energy. Regular is 48 Mhz, High is 88 Mhz. The default is Regular.
This option allows the configuration of the web server port number. The
valid range is 1-65535. The default is 80.
The Maximum Transmission Unit (MTU) is the largest physical packet size
a network can transmit for TCP and UDP. Enter between 512 and 1400
bytes. The default is 1400 bytes.
