- Page 1 HAWK ENTERPRISES FLOOR MACHINE OWNER’S MANUAL OPERATION – CARE – SERVICE COVERS ALL: EYAS .5 HP UNITS Hawk Enterprises 52744 Park Six Court Elkhart, IN 46514 Phone: 574-294-1910 Toll Free: 888-289-4295 Fax: 574-970-0289 Toll Free: 866-429-5329...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Service Information Important Safety Instructions Grounding Instructions Operations/Accessories Brush and Drive Block Installation Adjustments Controls Guidelines for Operation Cord Storage Clean Up and Storage Floor Machine Assemblies (.5 HP Units) Floor Machines Parts List 11-12 Optional Accessories Features Limited Warranty SERVICE INFORMATION... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTION When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS FLOOR MACHINE. WARNING: ELECTRICAL SHOCK CAN CAUSE SERIOUS INJURY OR BE FATAL. PLEASE READ THE FOLLOWING INSTRUCIONS ON THE USE AND OPERATON OF FLOOR FINISHING MACHINES. -
Page 4: Grounding Instructions
GROUNDING INSTRUCTIONS This appliance must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord that has an equipment-grounding conductor and grounding plug. -
Page 5: Operations/Accessories
GROUNDING INSTRUCTIONS (Continued) OPERATION / ACCESSORIES CHOOSING THE RIGHT BRUSH AND DRIVE BLOCK Your floor machine is packed completely assembled and ready for use after you install a brush or drive block. Your floor machine is designed to be used for many different floor care applications. Make sure you use the correct brush or pad for the type of job you want to perform. -
Page 6: Brush And Drive Block Installation
OPERATION / ACCESSORIES (Continued) When ordering brushes or drive blocks, refer to the following chart and specify correct brush or block diameter when ordering. PAD DRIVER BRUSH BRUSH BLOCK MACHINE SIZE DIAMETER DIAMETER DIAMETER 10" 9" 10" 8" 13" 12" 13"... -
Page 7: Adjustments
ADJUSTMENTS HANDLE ADJUSTMENT The handle can be adjusted to any desired work position by simply unlock pushing up on the handle lock. Move the handle to the desired position, then firmly push down on the handle lock which will lock the lock handle in position. -
Page 8: Guidelines For Operation
CONTROLS TO TURN THE MACHINE ON The operating handle must be lowered and locked to the proper operating position before switching the machine ON. Place both hands firmly on the handle grips with your fingers around the power triggers. Do NOT apply pressure on the triggers before the safety switch lock is disengaged. -
Page 9: Cord Storage
CORD STORAGE When not in use, loosely wind the power cord around the cord storage hook on the handle shaft and both of the handle grips, as shown: CLEANUP AND STORAGE After being used, your floor machine can be wiped clean with a soft, damp cloth and should be stored in a clean, dry place. -
Page 10: Floor Machine Assemblies (.5 Hp Units)
FLOOR MACHINE ASSEMBLIES .5 HP (175 RPM) -
Page 11: Floor Machines Parts List
ITEM PART QUANTITY NUMBER NUMBER PART DESCRIPTION REQUIRED 1 L0002 SW BX CVR LABEL-.5HP 1.0000 2 W0003-3P-1 SWTCH BX CVR-13 IN 1.0000 3 H0013 SWITCH INSULATION 1.0000 4 E0007 MAIN ON/OFF SWITCH 1.0000 5 C0003-1 SAFETY SWITCH 1.0000 6 H0014 SPRING 2LNG X .025 OD X.026 1.0000 7 L0005-1... - Page 12 43 S0040P BELT ADJ. BRACKET-LOWER, ZINC 1.0000 44 H0006 COTTER PIN - ZINC 3/32 X 1 1.0000 45 C0036M MACH-CLUTCH DRIVE CASTING EYAS 1.0000 46 H0056-5 1/4-20X2-3/4 SC CP SCRW BLK OX 3.0000 47 S0020-1P-10 13 BRUSH.COVER-HAMMER GRAY 1.0000 48 C0015-1 13 INCH BUMPER - RED 1.0000 49 L0001...
-
Page 13: Optional Accessories
OPTIONAL ACCESSORIES MACHINE SIZE 10" 13" 15" DESCRIPTION A0049 A0020 A0036 Polypropylene Brush A0050 A0021 A0035 Polish Brush A0048 A0016 A0037 Nylon Brush A0051 A0018 A0038 Grit Brush A0047M A0017 A0034 Pad Driver A0001-3BLACK A0001-3BLACK A0001-3BLACK Solution Tank (3 Colors – (Specify Color) (Specify Color) (Specify Color) -
Page 14: Limited Warranty
If repair is done on your equipment by anyone other than those designated by HAWK ENTERPRISES as authorized to perform such work, HAWK ENTERPRISES, at its sole option, may determine that this warranty will not apply and that reimbursement for such repair will not be made based on the failure to comply with such factory specified instructions.
