- Page 1 HAWK Red Tail 2014 HAWK Surface Prep Orbital Floor Machine ENTERPRISES Surface Prepara on, Scrubbing, Refinishing Operation Care Service HAWK ENTERPRISES 2902 Park Six Court, Elkhart, IN 46514 (574) 294-1910 (888) 289-4295 www.hawkenterprises.com...
-
Page 2: Table Of Contents
Service Information ....................2 Machine Specifications ....................3 Features ........................3 Important Safety Instructions ...................4 Grounding Instructions ..................5-6 Operations .......................7 Guidelines For Operations ..................7 Controls .......................7 Adjustments......................8 Cord Storage .......................8 Clean Up And Storage .....................8 Limited Warranty ..................Back Cover SERVICE INFORMATION To obtain consistent performance over the life of your equipment, read though these instructions and save them for future reference. -
Page 3: Machine Specifications
Model # REDTAIL2014 Part # F-REDTAIL-2014 Pad Size 20” X 14” Combination Pad Pad Driver Type Holder/Diamond Pad Driver Power Source 115V 60Hz 1.0 HP TEFC Motor/HP 1740 Rpm Amp Draw Vibration 1.25 Inches Compensator Cord 50’ 14-3 SJT Pad Pressure (lbs/in... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: WARNING: ELECTRIC SHOCK CAN CAUSE SERIOUS INJURY OR BE FATAL. PLEASE READ THE FOLLOWING INSTRUCTIONS ON THE USE AND OPERATIONS OF FLOOR FINISHING MACHINES. -
Page 5: Grounding Instructions
WARNING: RISK OF EXPLOSION. FLOOR SANDING MACHINE CAN RESULT IN AN EXPLOSIVE MIXTURE OF FINE DUST AND AIR. USE FLOOR SANDING MACHINE ONLY IN A WELL-VENTILATED AREA, FREE FROM ANY FLAME OR MATCH GROUNDING INSTRUCTIONS This appliance must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. -
Page 6: Grounding Instructions
WARNING: DO NOT USE GROUNDING ADAPTERS ON TIGERHAWKS IN CANADA. CHECK WITH CANADIAN CODE FOR PROPER EQUIPMENT USAGE. IMPROPER USE OF GROUND ADAPTORS CAN CAUSE SERIOUS INJURY, FIRE, OR BE FATAL. Grounding Instructions (Continued) -
Page 7: Operations
CONTROLS TO TURN THE MACHINE ON The operating handle must be lowered and locked to the proper operating position before switching the machine ON. Place both hands firmly on the handle grips with your fingers around the power triggers. Do NOT apply pressure on the triggers before the safety switch lock is disengaged. Disengage the safety switch lock by pushing it forward with one thumb. -
Page 8: Adjustments
ADJUSTMENTS HANDLE ADJUSTMENT The handle can be adjusted to any desired work position by simply pulling on the pull pin and move the handle to the desired position. Firmly push the pull pin back into the adjustment holes. This will lock the handle in position. Pull Knob Figure 5 CORD STORAGE... - Page 15 RED TAIL MAIN ASSY DETAIL PART NUMBER NUMBER DESCRIPTION REQ'D KIT1042 MOTOR KIT - RED TAIL INC IN KIT1042 MOTOR INC IN KIT1042 BOLT INC IN KIT1042 LOCWASHER KIT2037 SECONDARY ISOLATOR KIT - RED TAIL INC IN KIT2037 BOLT INC IN KIT2037 LOCKWASHER INC IN KIT2037 ISSOLATOR...
- Page 16 RED TAIL HANDLE ASSY KIT3009-1BLK CORD HOOK KIT (SQUARE) INC IN KIT3009-1BLK NUT 3/8-16 NYLOCK INC IN KIT3009-1BLK CAP CORD HOOK SQUARE BLK INC IN KIT3009-1BLK CORD HOOK SQUARE BLK INC IN KIT3009-1BLK BOLT HEX 3/8-16 X 2 INC IN KIT3009-1BLK WASHER FLAT BLK KIT2026-1 HANDLE MOUNTING HWDR KIT...
-
Page 17: Limited Warranty
If you are unable to locate any of the foregoing, you may write or otherwise communicate with HAWK ENTERPRISES before repair service is performed by anyone else. In such event, HAWK ENTERPRISES will provide either the location or a closely available HAWK distributor service department, or HAWK authorized service station or other factory instructions.
