- Page 1 HAWK 2014 HAWK Deluxe Orbital Floor Machine ENTERPRISES Dry Stripping, Scrubbing, Stripping Operation Care Service HAWK ENTERPRISES 2902 Park Six Court, Elkhart, IN 46514 (574) 294-1910 (888) 289-4295 www.hawkenterprises.com...
-
Page 2: Table Of Contents
Service Information ....................2 Machine Specifications ....................3 Features ........................3 Important Safety Instructions ...................4 Grounding Instructions ..................5-6 Operations .......................7 Guidelines For Operations ..................7 Controls .......................7 Adjustments......................8 Cord Storage .......................8 Clean Up And Storage .....................8 TigerHawk Assemblies ..................9-14 Optional Accessories ....................15 Limited Warranty ..................Back Cover SERVICE INFORMATION To obtain consistent performance over the life of your equipment, read though these... -
Page 3: Machine Specifications
Model # TH-2014 TH-2814 Part # F-TIGER2014 F-TIGER2814 Pad Size 20” X 14” 28” X 14” Combination Pad Combination Pad Pad Driver Type Holder/Diamond Pad Holder/Diamond Pad Driver Driver Power Source * 115V 60Hz 115V 60Hz 1.5 HP TEFC 1.5 HP TEFC... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: WARNING: ELECTRIC SHOCK CAN CAUSE SERIOUS INJURY OR BE FATAL. PLEASE READ THE FOLLOWING INSTRUCTIONS ON THE USE AND OPERATIONS OF FLOOR FINISHING MACHINES. -
Page 5: Grounding Instructions
WARNING: RISK OF EXPLOSION. FLOOR SANDING MACHINE CAN RESULT IN AN EXPLOSIVE MIXTURE OF FINE DUST AND AIR. USE FLOOR SANDING MACHINE ONLY IN A WELL-VENTILATED AREA, FREE FROM ANY FLAME OR MATCH GROUNDING INSTRUCTIONS This appliance must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. -
Page 6: Grounding Instructions
WARNING: DO NOT USE GROUNDING ADAPTERS ON TIGERHAWKS IN CANADA. CHECK WITH CANADIAN CODE FOR PROPER EQUIPMENT USAGE. IMPROPER USE OF GROUND ADAPTORS CAN CAUSE SERIOUS INJURY, FIRE, OR BE FATAL. Grounding Instructions (Continued) -
Page 7: Operations
CONTROLS TO TURN THE MACHINE ON The operating handle must be lowered and locked to the proper operating position before switching the machine ON. Place both hands firmly on the handle grips with your fingers around the power triggers. Do NOT apply pressure on the triggers before the safety switch lock is disengaged. Disengage the safety switch lock by pushing it forward with one thumb. -
Page 8: Adjustments
ADJUSTMENTS HANDLE ADJUSTMENT The handle can be adjusted to any desired work position by simply pulling on the pull pin and move the handle to the desired position. Firmly push the pull pin back into the adjustment holes. This will lock the handle in position. Pull Knob Figure 5 CORD STORAGE... -
Page 15: Optional Accessories
Optional integrated vacuum Transport cart that comes system (Dust skirt included with with each unit every TigerHawk) Optional spray system Miscellaneous Pads Backer Pads Floor Prep Pads Pads Sanding Screens... - Page 16 DETAIL PART NUMBER NUMBER DESCRIPTION QTY. TH1005 SECONDARY ISOLATOR KIT INC IN TH1005 KIT BOLT HEX 5/16-18X3/4 ZN INC IN TH1005 KIT WASHER 5/16 INTERNAL TOOTH INC IN TH1005 KIT ISOLATOR 1.25 INC IN TH1005 KIT NUT 5/16 NYLOCK THIN ZN TH1009 PRIMARY ISOLATOR KIT INC IN TH1009 KIT...
- Page 17 E0012-10 INHANDLE CORD MOTOR MAIN E0012-11 INHANDLE CORD VACUUN (IF EQUIPPED) HP0038 SAFETY SWITCH KIT INC IN HP0038 KIT SAFETY SWITCH INC IN HP0038 KIT SPRING 2 INCHES LING HP0095 TRIGGER KIT 14 INCH BLK INC IN HP0095 KIT ROLL PIN INC IN HP0095 KIT SPRING INC IN HP0095 KIT...
-
Page 18: Limited Warranty
If you are unable to locate any of the foregoing, you may write or otherwise communicate with HAWK ENTERPRISES before repair service is performed by anyone else. In such event, HAWK ENTERPRISES will provide either the location or a closely available HAWK distributor service department, or HAWK authorized service station or other factory instructions.
