EIVD28-870VF

700TVL Vandal Proof IR Dome Camera

FEATURES

• 1/3" Sony Super HAD CCD II

• Sony Effio-E DSP

• 700 TV Lines

• 4.0mm~9.0mm Varifocal Lens

• 28 IR LED; IR distance 60ft / 20m

• Various Angle LED Combination - Uniform IR light distribution for optimum

viewing angle

• 2DNR

• Photodiode Design for accurate IR LED trigger activation

• Double Glass: Effectively reducing the internal reflection

• Aluminum alloy housing design for better heat dissipation

• 12V DC / 110mA @ IR OFF ; 290mA @ IR ON

• IP66 Rating

www.sentryus.com

USER MANUAL

I-353

R201203-V08

Do you have a question about the EIVD28-870VF and is the answer not in the manual?

Page 1: User Manual
EIVD28-870VF 700TVL Vandal Proof IR Dome Camera USER MANUAL FEATURES • 1/3” Sony Super HAD CCD II • Sony Effio-E DSP • 700 TV Lines • 4.0mm~9.0mm Varifocal Lens • 28 IR LED; IR distance 60ft / 20m • Various Angle LED Combination - Uniform IR light distribution for optimum viewing angle •...
Page 2 Please read the Manual before attempting to use this product. Specifications and appearance are subject to change without notice. Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.
Page 3 7. Servicing Do not attempt to service this video product by yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all service to qualified servicing personnel. 8. Damage requiring service Unplug this video product from the wall outlet and refer service to qualified servicing personnel under the following conditions: a.
Page 4 Zoom: Focus Far / Near Lens Lens Adjustor Adjustor SPECIFICATION Model (NTSC) EIVD28-870VF Model (PAL) EIVD28-870VFP Sensor 1/3” Sony Super HAD CCD II Sony Effio-E Total Pixels NTSC: 1028(H) x 508(V) / PAL: 1028(H) x 596(V) Effective Pixels NTSC: 976(H) x 494(V) / PAL: 976(H) x 582(V)
