  • Page 1 HD-TVI Speed Dome Installation Manual UD.6L0201A1711A02...
  • Page 2 Installation Manual of HD-TVI Speed Dome Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact the dealer. This manual is applicable to HD-TVI Speed Domes. This manual may contain several technically inaccurate points or printing errors, and the content is subject to change without notice.

  • Page 3: Regulatory Information

    Installation Manual of HD-TVI Speed Dome Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Instruction

    Installation Manual of HD-TVI Speed Dome Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
  • Page 5 Installation Manual of HD-TVI Speed Dome otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.  Please use the provided glove when open up the dome cover, avoid direct contact with the dome cover, because the acidic sweat of the fingers may erode the surface coating of the dome cover.

  • Page 6: Table Of Contents

    Installation Manual of HD-TVI Speed Dome Table of Contents Chapter 1 Preparation ..............................1 Chapter 2 Installation ..............................2 Cable Descriptions ..............................2 DIP Switch Settings ..............................4 2.2.1 5-inch Speed Dome Settings ..........................4 2.2.2 5-inch IR Speed Dome Settings ........................5 2.2.3 7-inch IR Speed Dome Settings ........................

  • Page 7: Chapter 1 Preparation

    Installation Manual of HD-TVI Speed Dome Chapter 1 Preparation Basic Requirement  All the electronic operation should be strictly compliance with the electrical safety regulations, fire prevention regulations and other related regulations in your local region.  Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included.

  • Page 8: Chapter 2 Installation

    Installation Manual of HD-TVI Speed Dome Chapter 2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Start Installation Preparation Wiring Installing Bracket Setting DIP Switch Installing Speed Dome...
  • Page 9 Installation Manual of HD-TVI Speed Dome ① Black Yellow&Green ① AC24V YELLOW/GREEN GND Yellow Orange BLACK AC24V ② Video Output ② YELLOW R485- ORANGE R485+ Figure 2-2 Cables of 7-inch IR Speed Dome Name Description AC24V Power supply RS485+/- 485 control VIDEO Coaxial and analog video output ①...

  • Page 10: Dip Switch Settings

    Installation Manual of HD-TVI Speed Dome 2.2 DIP Switch Settings 2.2.1 5-inch Speed Dome Settings The DIP switch is used for setting the address and baudrate for the speed dome, with value ON=1 and OFF=0. The SW1 switches from the first to the eighth are used to set the address. The SW2 switches are used to set the baudrate.

  • Page 11: 5-Inch Ir Speed Dome Settings

    Installation Manual of HD-TVI Speed Dome  Address Settings The SW1-switches from 1 to 8 are used for setting the address of speed dome. You can refer to Table 2-1 for details of setting the speed dome address to a specific number. Table 2-1 Set the Dome Address between 0 and 255 Switch No.
  • Page 12 Installation Manual of HD-TVI Speed Dome Screws Switch Cover DIP Switch Figure 2-7 Position of DIP Switch for 5-inch IR Speed Dome  Setting DIP Switch Figure 2-8 Enlarged View of DIP Switch  For some certain models, the two individual DIP switches at the left side of the Figure 2-8 are supported for turning on/off the terminator;...
  • Page 13 Installation Manual of HD-TVI Speed Dome For convenient settings, refer to the following list to set the address for the speed domes. Table 2-4 Dome Address Switch Dome Address  Baudrate List For convenient settings, refer to the following list to set the baudrate for the speed dome. The baudrate will be set as 2400bps by default if it is out of this range.

  • Page 14: 7-Inch Ir Speed Dome Settings

    Installation Manual of HD-TVI Speed Dome Table 2-5 Baudrate Switch Baudrate 2400 4800 9600 19200  Protocol List For convenient settings, refer to the following list to set the protocol for the speed dome. Table 2-6 Protocol Protocol Self-adaptive Pelco_D Pelco_P AD Manchester The speed dome is self-adaptive to private protocol when the No.8 and 9 switches are both OFF.
  • Page 15 Installation Manual of HD-TVI Speed Dome Figure 2-10 Enlarged View of DIP Switch The default dome address is 0; the default baudrate is 2400; and the default value of the 120Ω terminator is OFF.  Address Settings The SW1 switch is used for setting the address of speed dome. You can refer to Table 2-7 for details of setting the speed dome address to a specific number.

  • Page 16: Mini Speed Dome Settings

    Installation Manual of HD-TVI Speed Dome Table 2-9 Set Communication Mode of the Dome DIP Switch SW2-Simplex/Half-duplex Settings Description Simplex Half-duplex  Terminal Resistor Settings The No. 8 of SW2 switch is used for turning on/off the 120Ω terminal resistor. Table 2-10 Set Terminal Resistor Switch No.
  • Page 17 Installation Manual of HD-TVI Speed Dome DIP Switch Figure 2-12 DIP Switch of Mini Analog Speed Dome  Setting DIP Switch Figure 2-13 Enlarged View of DIP Switch  For some certain models, the two individual DIP switches at the left side of the Figure 2-8 are supported for turning on/off the terminator;...

  • Page 18: Wiring And Installation

    Installation Manual of HD-TVI Speed Dome Table 2-12 Dome Address Switch No. Dome Address … … … … … …  Baudrate List For convenient settings, refer to the following list to set the baudrate for the speed dome. The baudrate will be set as 2400bps by default if it is out of this range.

  • Page 19: Installing The Bracket

    Installation Manual of HD-TVI Speed Dome power supply and a reasonable wiring route.  Get familiar with the installation environment before deploying the wire, including the wiring distance, surrounding, and electromagnetic interference and so on.  Please choose the cable with nominal voltage higher than the actual voltage, to ensure a normal running in case of unsteady voltage.

  • Page 20: Setting The Dip Switch

    Installation Manual of HD-TVI Speed Dome Figure 2-16 Secure the Bracket 5. Install the speed dome to the bracket. Please refer to Section 2.3.4 Installing the Speed Dome for installation details. Follow the same instructions described above for the short-arm wall mounting. For outdoor applications, please adopt the water-proof measures.
  • Page 21 Installation Manual of HD-TVI Speed Dome ① ② ③ Figure 2-17 Mount the Dome 2. Route the cables of the speed dome through the bracket. 3. Connect the corresponding video/power/RS-485 cables. 4. Install the speed dome to the bracket, and secure the speed dome by rotating the speed dome clockwise.

  • Page 22: Chapter 3 In-Door Mounting Applications

    Installation Manual of HD-TVI Speed Dome Chapter 3 In-door Mounting Applications Before you start:  For cement wall, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket. ...
  • Page 23 Installation Manual of HD-TVI Speed Dome Figure 3-2 Draw and Cut Hole on the Ceiling 6. Connect the cables. Make sure the video cable and control wire have been connected to the corresponding interfaces. Connect the power cable and the red LED indicator turns on when the power is on. Please turn the power off after checking the speed dome.

  • Page 24: 5-Inch Speed Dome Ceiling Mounting Applications

    Installation Manual of HD-TVI Speed Dome 8. Install the trim ring. (1) Attach the trim ring to the lower dome and align the triangular notch of the trim ring with the arrow label on the in-ceiling mounting bracket. (2) After having firmly placed the trim ring to the ceiling, rotate the trim ring in the direction of arrow to secure the trim ring in place.
  • Page 25 Installation Manual of HD-TVI Speed Dome Figure 3-6 Remove 4 screws 2. Remove the in-ceiling mounting bracket. Figure 3-7 Remove the in-ceiling mounting bracket 3. Screw 4 bolts onto the back box by a Phillips screwdriver. Figure 3-8 Install the bolts...

  • Page 26: Wiring

    Installation Manual of HD-TVI Speed Dome 3.2.2 Wiring The cables of dome can be routed either from the top or the side of the back box. For the cables routed from the top of the back box, it is required to drill a cable hole in the ceiling. Figure 3-9 Cabling for Ceiling Mounting 3.2.3 Ceiling Mounting Steps:...
  • Page 27 Installation Manual of HD-TVI Speed Dome  If the dome is installed to the cement wall, drill three Φ5 mounting holes onto the wall according to the hole locations, and then insert the cement screws into the holes and finally use self-tapping screws to secure the mounting base to the wall. Screw Holes Cable Hole Figure 3-11 Secure the Mounting Base...

  • Page 28: Mini Speed Dome In-Ceiling Mounting Applications

    Installation Manual of HD-TVI Speed Dome  Please remove the protective film on the lower dome after the installation is finished.  Do not touch the bubble of the lower dome directly by hand. The image blurs otherwise. 3.3 Mini Speed Dome In-ceiling Mounting Applications 3.3.1 Mini Analog Speed Dome In-ceiling Mounting Before you start: The in-ceiling mounting is applicable to the indoor ceiling construction.
  • Page 29 Installation Manual of HD-TVI Speed Dome Protective Foam Notch Lower Dome Back Box Sticker Figure 3-14 Disassemble the Speed Dome 3. Install the toggle bolts. 1) Remove the toggle from the toggle bolt. 2) Insert the bolts into the screw holes on the dome. 3) Rotate the bolts through the screw holes.

  • Page 30: Mini Ir Speed Dome In-Ceiling Mounting

    Installation Manual of HD-TVI Speed Dome Screws Figure 3-17 Install the Lower Dome 8. Route the cables through the ceiling for the speed dome. Please refer to the section 2.1 Cable Descriptions for connecting the cables. 3.3.2 Mini IR Speed Dome In-ceiling Mounting Before you start: The in-ceiling mounting is applicable to the indoor ceiling construction.
  • Page 31 Installation Manual of HD-TVI Speed Dome Connecting the Cables for connecting the cables. 4. Install the toggle bolts. 1) Remove the toggle from the toggle bolt. 2) Insert the bolts into the 3 screw holes on the dome. 3) Rotate the bolts through the 3 screw holes. 4) Reinstall the toggles as shown in Figure 3-19.

  • Page 32: Mini Speed Dome Ceiling Mounting Applications

    Installation Manual of HD-TVI Speed Dome 3.4 Mini Speed Dome Ceiling Mounting Applications Before you start: The ceiling mounting is applicable to the indoor/outdoor solid ceiling construction. The followings are the mandatory precondition for ceiling mounting:  The ceiling must be with the thickness between 5 and 40mm. ...
  • Page 33 Installation Manual of HD-TVI Speed Dome 1) Loosen three screws on the notch. 2) Remove the lower dome. 3) Remove the protective lens cover, foam and sticker from the dome drive as shown in Figure 3-24. Protective Foam Notch Lower Dome Lens Cover Sticker Figure 3-24 Disassemble the Speed Dome...
  • Page 34 Installation Manual of HD-TVI Speed Dome  For cement ceiling mounting, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket.

  • Page 35: Appendix

    Installation Manual of HD-TVI Speed Dome Appendix Appendix 1 Lightning & Surge Protection This product adopts TVS plate lightning protection technology to avoid damage caused by pulse signal that is below 3000W, like instantaneous lighting stroke, surging, etc. According to the actual outdoor situation, necessary protection measures must be taken, besides ensuring the electrical safety.

  • Page 36: Appendix 2 Rs485 Bus Connection

    Installation Manual of HD-TVI Speed Dome Appendix 2 RS485 Bus Connection  General Property of RS485 Bus According to RS485 industry bus standard, RS485 is a half-duplex communication bus which has 120Ω characteristic impendence, the maximum load ability is 32 payloads (including controller device and controlled device).
  • Page 37 Installation Manual of HD-TVI Speed Dome faraway. At this time, the dome will be uncontrollable, or self-running, etc. Controller Figure A-4 Star Shape Connection For such case, the best way is adding a RS485 distributor. This product can effectively change the star-shape connection to which satisfies the requirement of RS485 industry standard, in order to avoid those problems and improve the communication reliability.
  • Page 38 Installation Manual of HD-TVI Speed Dome Problem Possible Reasons To Solve the Problem dome can tightly. 2. RS485+ or RS485-wire is 2. Change a RS485 wire. controlled broken. but not 3. The speed dome is too far away 3. Add a terminal resistor. smoothly.

  • Page 39: Appendix 3 24Vac Wire Gauge & Transmission Distance

    Installation Manual of HD-TVI Speed Dome Appendix 3 24VAC Wire Gauge & Transmission Distance The following table describes the recommended Max. distance adopted for the certain wire gauge when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum voltage loss rate is 10% allowable.

  • Page 40: Appendix 4 Wire Gauge Standards

    Installation Manual of HD-TVI Speed Dome Appendix 4 Wire Gauge Standards American Cross-sectional Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663 2.000 3.1420 2.500 4.9080 3.000...
