ESFL-X650
Motion LED Floodlight Covert Color Camera
FEATURES
1/3" Sony ExView HAD CCD II
650 TV Lines (Color) / 700TV Lines (B&W)
3.6mm Board Lens
0.01 Lux @ F2.0; 0 Lux @ IR on
150pcs High Efficiency White Light LED
140° PIR motion sensor
Pyro-Sensor Detection; Up to 50ft / 15m
IP55 Rating
650mA @ LED on / 110mA @ LED off
12V DC
This motion floodlight covert camera has 150pcs high efficiency white light LED for
energy saving and longer life time. It also features a 140° PIR motion sensor with no
dead-angle wide view design. With its IP55 weatherproof housing, this motion floodlight
covert camera is suitable for garage, entrance, warehouse, corridor, parking lot, garden,
street, etc. where lighting and security is needed.
Copyright © 2012. All Rights Reserved.
www.sentryus.com
Operational Manual
Camera
1
H-510
R201212-V11
Advertisement
Table of Contents
Related Manuals for Sentry US ESFL-X650
Summary of Contents for Sentry US ESFL-X650
- Page 1 ESFL-X650 Operational Manual Motion LED Floodlight Covert Color Camera Camera FEATURES 1/3” Sony ExView HAD CCD II 650 TV Lines (Color) / 700TV Lines (B&W) 3.6mm Board Lens 0.01 Lux @ F2.0; 0 Lux @ IR on ...
- Page 2 Please read the Manual before attempting to use this product. Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.
- Page 3 Handle this camera with care Avoid any shock or bumping of the camera. Improper handling could damage the camera. Requires a proper operating environment This camera is designed for outdoor use. The allowable temperature range for operation of this camera is between -40°F ~ 122°F / -40C ~ 50C. Clean the front face or lens It is recommended that the surface be cleaned every 3~6 months.
- Page 4 Camera is modified in any way If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be voided immediately. It is the customer’s responsibility to keep the camera in good condition. Video or power cable is cut The video cable and the power cable should not be tampered with.
- Page 5 VR ADJUSTMENTS ► Decreases detection range to Min. 5M “–”-wise SENS: – / + ► Increases detection range to Max. Sensitivity Setting “+”-wise 15M (based on 22°C) ► Standby on 24 hours “☼”-wise LUX: ☼ / ► Standby at nighttime “...
- Page 6 SPECIFICATIONS Model (NTSC) ESFL-X650 Model (PAL) ESFL-X650P 1/3” Sony ExView HAD CCD II Image Sensor Effective Picture NTSC: 976(H) x 494(V) Elements PAL: 976(H) x 582(V) Resolution 650 TV Lines (Color) / 700TV Lines (B&W) Minimum 0.01 Lux @ F2.0, 0 Lux @ IR on...
- Page 7 OTHER COVERT CAMERAS Covert PIR Color Camera with Audio Covert PIR Color Camera ESP-3420A ESP-3420 1/3” Sony Super HAD CCD 1/3” Sony Super HAD CCD 420 TV Lines 420 TV Lines For Indoor Only For Indoor Only ...
- Page 8 OTHER COVERT CAMERAS Covert UFO Color Camera Covert Mirror Camera ESU-3420 ESM-N520-OSD 1/3” Sony Super HAD CCD 1/3” Sony Super HAD Hi-Res. CCD 420 TV Lines 520 TV Lines 3.7mm Cone Lens 3.7mm Board Lens ...
