User Manual
DVR
4 Channel Full D1 H.264 DVR
SHDVR-04
Security Cameras
1/3" Sony Ex-View
HAD II CCD
Sony DSP
12V DC
Different kits
available with
different cameras
650 TVL
EIR24-3650
Accessories
100ft Combo Cable
x4 -- 1 for each camera
BP030-W
PDCMF124
DVR Accessories
24 IR Effi o-E
Waterproof Bullet
EIR42X-450VF
EIR42X-460VF
EIR42X-470VF
1-in 4-out Power
12V DC 2Amp
Splitter
Power Transformer
P12DC2AMP
for Sentry Cameras & 4-CH DVR Package Kit
42 IR Effi o-E
Weatherproof Bullet
500 TVL
600 TVL
700 TVL
16" Male DC Cord
to Camera DC plug
PDC-M
Quick Start Guide
Quick
Setup
Guide
CD
35 IR Weatherproof
Bullet Camera
1/3" Sony CCD
480 TVL
EIR35-F4840
12V DC 10Amps UL
Power Supply Box
P12DC9PUL-10
Remote
Control
Manual
36 IR Effi o-E
Weatherproof Dome
Black or White Base
EIVD36-450VF
500 TVL
EIVD36-460VF
600 TVL
EIVD36-470VF
700 TVL
BNC Male to RCA
Female
*RCA cable not included
Adapter
