OSD STRUCTURE-


MENU
MODE
EXPOSURE
WHITE BAL
INTELLIGENCE
SPECIAL FUNC
DISPLAY
EXIT
▶ SHARPNESS :
• 0 ~ 10 steps
▶ MIRROR :
Select a flip mode
• OFF / H / V / H&V
· H : You can flip the picture horizontally on the screen
· V : You can flip the picture vertically on the screen
· H&V : You can flip the picture horizontally & vertically on the screen
▶ Freeze :
Select real or still mode
• OFF / ON
▶ D.ZOOM :
Select maximum digital zoom magnification.
• x1 ~ x12, x14, x15, x18, x21, x25, x32
▶ HLC :
Select High Light Compensation.
When extremely bright light is projected to the camera masking is used on the
portion to prevent partial saturation on the monitor.
• OFF / ON
· ON LEVEL : 0 ~ 20 steps
COLOR : Black, White, Yellow, Cyan, Green, Magenta, Red, Blue
48 MICRODIGITAL
Adjust sharpness level
MAIN MENU
SHARPNESS
MIRROR
FREEZE
D.ZOOM
HLC
ACE
DNR
D.COMPRESS
RETURN
5
OFF
OFF
X1
OFF
OFF
AUTO
OFF
