COMPONENTS
MDC-H7290F / V, VTD, VTD-30 (100Ø)
1 Lens
2 3 Axis bracket
· Adjust the pan and tilt to give the correct angle of view.
3 OSD Joystick / Board
4 VBS-Extra for connecting to LCD
· Please use the supplied wire when connecting to an external monitor.
5 IR LED
MDC-H7290VTD
MDC-H7290F
1
1
2
2
3
3
1
4
5
VBS-EXTRA
2
3
3
MDC-H7290VTD-30
MICRODIGITAL
25
