INSTALLATION
MDC-H7xxx
• Open the dome with the ring unscrewed.
• There are two mounting holes on the dome base so that users can install the unit
in any place such as on the ceiling, on the wall, on the fence and etc.
• The mounting in any place connecting the video/power cable, before connecting
please check the below point.
• Adjust picture direction pan & tilting.
• Close the dome with the ring screwed.
L-Wrench
MDC-H7290VTD /
(Three Screw)
32
MICRODIGITAL
Ceiling
BASE HOUSING
MOUNTING SCREW
DOME COVER
HOLDER
DOME COVER
Ceiling
L-Wrench
MDC-H7290VTD-30
(Three Screw)
