COMPONENTS
MDC-H4290C / CTD

Over view

3 Back focus clamp screw & Hole
1 Lens protection cap 4 Mount bracket
2 CS-MOUNT Lens adaptor
1 Lens protection cap
Cover the lens when not in use.
2 CS-mount lens adaptor
Attach the CS-mount lens here, and if you want to use C-mount lens, also please
attach C-ring to the CS-mount and then also
3 Back focus clamp screw
Loosen the clamp screw with a L-Wrench before adjusting the Back Focal length.
4 Mount bracket
Use the screw holes provided when fixing the camera onto a mounting bracket.
The mounting bracket can be attached to either the bottom or the top of the camera.
