Summary of Contents for Sony Trimaster PVM-L3200

  • Page 1 LCD VIDEO MONITOR PVM-L3200 OPERATION MANUAL [English] 1st Edition (Revised 1)
  • Page 2 WARNING Before operating the unit, please read this manual thoroughly and retain it for future reference. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Important Safety Instructions To avoid electrical shock, do not open the •...
  • Page 3 Electromagnetic Environment: E4 (controlled EMC Dette utstyret kan kobles til et IT-strømfordelingssystem. environment, ex. TV studio). Apparatet må tilkoples jordet stikkontakt The manufacturer of this product is Sony Corporation, 1- Suomessa asuville asiakkaille 7-1 Konan, Minato-ku, Tokyo, Japan. Laite on liitettävä suojamaadoituskoskettimilla...

  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Overview Precautions ................7 On Safety ..................7 On Installation ................7 Handling the LCD Screen ............7 With Protection Plate Installed........... 7 On Cleaning................8 On Repacking ................8 On Rack Mounting ..............8 Functions Supported in Software Version 1.1 ....9 Features ................
  • Page 5 Chroma/Phase Adjustment ............31 Color Temperature (White Balance) Adjustment.....32 Brightness/Contrast Adjustment ..........32 Chapter 3 Menu Basic Menu Operations............33 Menu Operation Buttons............33 Displaying the Menu..............34 Setting or Adjusting in the Menu Operation......34 Entering the Channel Number ..........36 Aborting Menu Operation............36 Menu Structure ..............37 Adjustment Menu..............44 Overview...................44 Menu Function and Operation ..........44...
  • Page 6 Setting the Display of Native Scan Mode ......83 Selecting the Native Scan/Scan Mode ......84 Displaying Two Signals on One Screen (Picture&Picture) ............ 85 Magnifying the Picture (Pixel Zoom) ......... 86 Displaying the Picture in Black Detail Mode ....87 Capturing the Picture of the HD Signal (HD Frame Capture) ..........

  • Page 7: Chapter 1 Overview

    Overview Chapter of pixels may be “stuck”, either always off (black), Precautions always on (red, green, or blue), or flashing. In addition, over a long period of use, because of the physical characteristics of the liquid crystal display, such “stuck” pixels may appear spontaneously.

  • Page 8: On Cleaning

    If you have any questions about this unit, please contact On Cleaning your Sony service representative. Before cleaning Be sure to disconnect the AC power cord from the AC outlet. On cleaning the monitor screen The monitor screen surface is especially treated to reduce reflection of light.

  • Page 9: Functions Supported In Software Version 1.1

    Functions Supported in Software Version 1.1 The following new functions are supported for Version 1.1 of the PVM-L3200. Menu Supported function Reference page • Checkerboard Simultaneous display or left/right switching display of 65, 68, 80, 91 the left and right 3D video signals is available by •...

  • Page 10: Features

    SD-SDI, RGB, YPbPr, Y/C and composite signal input. system. * HDMI, the HDMI logo and High-Definition Multimedia * TRIMASTER is a trademark of Sony Corporation. Interface are trademarks or registered trademarks of HDMI Licensing LLC. 32-inch LCD panel developed for the PVM The 32-inch (31.55 inch) LCD panel was developed for the...
  • Page 11 Audio level meter/time code display function For the operation, see “Displaying the Area Marker or Aspect Marker” on page 89. Audio level of the embedded audio and time code signals superimposed on the SDI signals are displayed by Scan selection/Native scan display function installing the optional input adaptor (BKM-250TG).

  • Page 12: Options

    BKM-229X Analog Component Input Adaptor Options Includes a decoder for analog component signals and analog RGB signals. Input connector for one channel is equipped. For external control BKM-243HS HD/D1-SDI Input Adaptor Includes a decoder for serial digital component signals. BKM-16R Monitor Control Unit Input/output connectors for two serial digital channels and The BKM-16R is a controller of the PVM-L3200 and you output connector for one monitor channel are equipped.

  • Page 13: Input/Output Connector And Adaptor

    or work correctly, or you may not be satisfied with the performance if designated input adaptors are not installed. BKM-250TG: The 3D signal analyzing function does not operate if designated input adaptors are not installed. Input/Output Connector and Adaptor By adding the optional input expansion adaptors, the input/ output connector panel can be assembled in a wide variety of configurations.
  • Page 14 Input adaptor BKM- BKM- BKM- BKM- BKM- 220D 227W 229X 243HS/ 250TG Input signal 244CC Component 525/ Single-link HD-SDI Dual-link HD-SDI a(2) Single-link 3G-SDI Composite NTSC Composite PAL Composite PAL-M Composite SECAM Y/C NTSC Y/C PAL Y/C PAL-M Y/C SECAM YPbPr 525i/625i RGB 525i/625i YPbPr/RGB...

  • Page 15: Location And Function Of Parts

    Location and Function of Parts Front Panel 1 Tally lamp 6 OPTION B connector 2 OPERATE lamp 5 OPTION A 3 STATUS lamp connector 4 OVER RANGE lamp a Tally lamp Notes With factory settings, the tally lamp lights when pins No. 8 and No.
  • Page 16 –: Status except for error display. Error display If the error is shown, please contact your Sony representative. OVER STATUS OPERATE...

  • Page 17: Rear Panel/Left Side Panel

    Rear Panel/Left Side Panel 1 ?/a switch 2 AC IN connector 3 CONTROL UNIT connector 4 LAN (10/100) connector 5 NETWORK switch 6 PARALLEL REMOTE connector 7 DVI-D input connector 8 HDMI IN connector 9 Input option slots a ?/a (main power) switch Connect to the DC 5V/12V IN connector of the controller When turned on (?), the monitor enters operation mode.
  • Page 18 • When you connect the LAN cable of the unit to To switch each function between On and Off or between peripheral device, use a shielded-type cable to prevent enable and disable, change pin connections in the malfunction due to radiation noise. following way.

  • Page 19: Chapter 2 Preparations

    Preparations Chapter Environments of the Installation Location Illumination environments Viewing angle The apparent color reproduction on the monitor is greatly The ideal viewing angle is within 5 degrees (up/down/left/ affected by ambient light or glare. right) off the center of the monitor screen when the The LCD device controls the brightness by moving LCD operator views the entire monitor screen.

  • Page 20: Installing An Input Adaptor

    Insert the adaptor facing the board as shown below. Installing an Input Adaptor Board Each input adaptor can be installed in any input option slot on the side panel. Caution When you install the following input adaptors to this equipment, use those with the serial numbers given below. •...

  • Page 21: Removing The Protection Plate

    OPTION 1 and 2 option slots, or OPTION 3 and 4 option Removing the Protection slots. Plate Example of Dual-link cable connection The protection plate is installed on the monitor at the factory to protect the LCD panel. INPUT 1 You can remove the protection plate if you wish to avoid the difference in color and/or reflection on the screen with INPUT 2...

  • Page 22: Mounting The Unit In A Rack

    Remove the protection plate. Mounting the Unit in a Protection plate Rack When you mount the monitor in a rack, be sure to take measures to prevent it from falling or shifting. If the front stands of the monitor protrude from the rack, you can change the mounting direction of the stands when installing the monitor.

  • Page 23: Attaching The Bracket

    Attach a piece of string, etc. to the bracket and secure Attaching the Bracket it to the floor or wall. You can prevent falling of the monitor by using the supplied bracket. Remove three screws from the bracket. Bracket Bracket (supplied) String, etc.

  • Page 24: Connections

    Connecting the Controller (BKM- Connections 16R) Note on connecting the cable to the CONTROL UNIT connector Monitor Be sure to plug the male connector of the cable into the CONTROL UNIT connector of the monitor. Insert the connector so as to fit the shape of the CONTROL UNIT connector.

  • Page 25: Connecting The Multiple Units With The Lan

    Or connect the output cable of the AC adaptor supplied with the controller to the DC 5V/12V IN connector of the controller. PEER TO PEER NETWORK Connecting the Multiple Units with the LAN Set to LAN. Monitor Monitor The controller controls up to 32 monitors. Up to four controllers are connected to one monitor in single mode.

  • Page 26: Turning On The Power

    of a straight/cross cable. Turning on the Power When the switching hub without auto selection function is used, connect the monitor and switching hub with the straight cable, and the controller and switching hub with the cross cable. Connecting the AC Power Cord Connect the output cable on the AC adaptor supplied with controller to the DC 5V/12V IN connector of the Plug the AC power cord into the AC IN connector on...

  • Page 27: Settings

    Settings Selecting the Area When you turn on the monitor for the first time after purchasing it, select the area where you intend to use this monitor from among the options. The warm-up time is more than 30 minutes, approximately. When the area is selected, the menu item settings suitable for the selected area are applied.
  • Page 28 If 4 Asia Except Japan is selected: Select Area NTSC area Asia Except Japan NTSC Area PAL Area PAL area ENTER button UP/DOWN buttons Ent button Customers who will use this monitor in the shaded Turn on the monitor with the ?/a (main power) switch. areas shown in the map below should select NTSC Area.

  • Page 29: Setting For The Lan To Connect The Multiple Units

    After saving and reflecting the setting, you can change the Controller: Set the IP address in the Network Setting setting with the menu. menu (page 77) of the Controller menu. • Color Temp (color temperature) (page 52) • Setup Level (NTSC Setup Level: page 54, Betacam Set Monitor ID and Group ID in the Network menu Setup Level: page 54) (page 66) of the System Configuration menu.

  • Page 30: Assigning The Input Signal To The Channel

    Assigning the Input Signal to the Channel When you assign the input signal to the channel, you can select the channel and change the input signal by pressing Display window the numeric button. The input signal is assigned to one of channels 1 to 30.

  • Page 31: Adjusting

    Automatic adjustment (recommended) Adjusting Input the reference color-bar signal to the monitor. Select Auto in the Picture Adj menu of the Adjustment Before adjusting menu and perform the automatic adjustment of the The monitor must be warmed up sufficiently. chroma, phase and matrix in Auto Adjust (page 44). To perform stable color reproduction, turn on the power of the monitor, display the white signal and leave it in this Manual adjustment...

  • Page 32: Color Temperature (White Balance) Adjustment

    The following are explained as the example when the Color Temperature (White Balance) multi format color-bar signal is used for adjustment. Adjustment Select the Manual Adjust menu (page 45) in the Picture Adj menu of the Adjustment menu. You can adjust manually or automatically with a specified color temperature probe.

  • Page 33: Chapter 3 Menu

    Menu Chapter Basic Menu Operations Menu Operation Buttons The menu is operated using the menu operation buttons on the controller (BKM-16R, optional). Controller (BKM-16R) 1 UP/DOWN buttons 2 MENU button 3 ENTER button 4 PHASE knob REMOTE INPUT CHROMA CONTRAST PHASE BRIGHT SINGLE...

  • Page 34: Displaying The Menu

    The current settings are displayed in place of the x Displaying the Menu marks on the illustrations of the menu screen. Press the MENU button. iInput Configuration The main menu is displayed on the screen. CH01 Format Slot No: xxxxx Input No: xxxxx MENU...

  • Page 35: Entering Characters

    When selecting in setting mode The cursor moves to the setting value and the monitor enters in setting mode. Using the UP or DOWN button or PHASE knob, select Display example the desired item and press the ENTER or Ent button. The cursor moves to the setting value and the monitor iInput Configuration enters in setting mode.

  • Page 36: Entering The Channel Number

    When you press the UP button or turn the PHASE knob 094: Five-step gray scale signal clockwise, the characters and symbols appear in the 095: Ramp signal sequence shown below. 096: color-bar signal Capital letters (A t B t ..t Y t Z) t Lower- 097: 0% black signal case letters (a t b t ..

  • Page 37: Menu Structure

    Menu Structure For details of each menu, see the page in parentheses. Adjustment menu (page 44) Main menu Level 1 Level 2 Level 3 Level 4 Adjustment Picture Adj Auto Auto Adjust Color Bar Restore Factory Data Status Slot No Format Matrix Manual Adjust...
  • Page 38 Input Configuration menu (page 50) Main menu Level 1 Level 2 Level 3 Level 4 Input Configuration Format 3G/HD/SD-SDI Dual Link HD-SDI Composite Component HDMI Slot No Input No Screen Aspect Sync Mode HDMI Auto Color Temp Picture Preset Matrix/Gamma DVI/HDMI Computer HDMI Auto Color Gamut...
  • Page 39 Display Function menu (page 58) Main menu Level 1 Level 2 Level 3 Level 4 Display Function Marker Setting Aspect Blanking Aspect Blanking Mode Aspect Marker Aspect Marker Aspect Mode Aspect Line Color Bright Area Marker 1 Area Marker 1 Aspect Mode Aspect Area Size...
  • Page 40 Main menu Level 1 Level 2 Level 3 Level 4 Capture Load Rename Delete Internal Signal Function Switch Scan Mode Native Scan 16:9 H Delay V Delay External Sync Comb Aperture Mono Blue Only R Off G Off B Off Chroma Up Black Frame Insertion Interlace...
  • Page 41 System Configuration menu (page 66) Main menu Level 1 Level 2 Level 3 Level 4 System Configuration Network Monitor ID Group ID Network Setting IP Address Subnet Mask Default Gateway Address SNMP Setting Contact Name Location Trap Mode Trap Address Setting Trap Address Status Reset Mode/Address Community...
  • Page 42 File Management menu (page 73) Main menu Level 1 Level 2 Level 3 Level 4 File Management Save To Memory Stick Copy From Other Monitor Monitor ID Memory Stick Delete Memory Stick Data Maintenance Back Up System Data Restore System Data Status menu (page 75) Main menu Level 1...
  • Page 43 Controller menu (page 77) / Key Protect menu (page 81) Main menu Level 1 Level 2 Level 3 Level 4 Controller Network Network Setting IP Address Subnet Mask Default Gateway Address SNMP Setting Contact Name Location Trap Mode Trap Address Setting Trap Address Status Reset Mode/Address Authentication...

  • Page 44: Adjustment Menu

    Adjustment Menu Overview Adjusts the picture, color temperature, etc. Note When Adjustment is selected, the following menu is displayed. This menu is not selectable in the following cases: • When Side by Side is set to On iAdjustment Picture Adj Color Temp Adj Position Adj Menu Function and Operation...
  • Page 45 Menu Function and operation ([ ]: factory setting) Color Bar Sets the color-bar signal to input. [Full Field 8]: 100% full-field 8-color bars (white, yellow, cyan, green, magenta, red, blue and black) SMPTE: SMPTE standard color bars EIA: EIA standard color bars (effective for 480/60i and 575/50i signals only) Multi Format: Color bars standardized by SMPTE RP219/ARIB STD-B28 Restore Factory Data Resets the automatic adjustment data of chroma, phase, matrix and signal level to the default...
  • Page 46 Menu Function and operation ([ ]: factory setting) Color Temp Adj Adjusts the color temperature. When the item is selected, the color temperature data to be adjusted is displayed. When D93 or D65 data is changed, they are displayed as D93* or D65*. To change the color temperature data to be adjusted, select D93, D65, User1, User2, User3, User4 or User5 in the Color Temp menu of the Input Configuration menu.
  • Page 47 Menu Function and operation ([ ]: factory setting) Contrast Hold Sets whether or not to adjust the color temperature and contrast (backlight) at the same time. Off: Contrast is adjusted. [On]: Contrast is not adjusted. Auto Adjusts the color temperature automatically by using an optional probe. When the item is selected, the color temperature data to be adjusted is displayed.
  • Page 48 Eye-One Pro. Before adjusting the color temperature automatically, start the software for adjusting the color temperature. For the software for adjusting the color temperature, please contact your Sony representative. For more information about the cable specification required and about the connection, see “Connection Cable Specifications for Color Temperature Probes”...
  • Page 49 Menu Function and operation ([ ]: factory setting) Restore Factory Data Resets the color temperature to the default setting. You cannot select this when the setting is the default value. The following message appears to confirm the data reset operation. Restore factory data? OK: To reset the data, press the ENTER (Ent) button.

  • Page 50: Input Configuration Menu

    Input Configuration Menu Overview This menu is used for pertaining data to the input signals. When Input Configuration is selected, the following menus are displayed. iInput Configuration iInput Configuration iInput Configuration CH01 CH01 CH01 Format Marker Preset: xxxxx Copy From Slot No: xxxxx H Shift Offset:...
  • Page 51 Menu Function and operation ([ ]: factory setting) When BKM-250TG is installed 3G/HD/SD-SDI Auto: Changes the format automatically according to the Sampling Structure, Bit Depth, Picture and transport scanning method information for Payload ID of SMPTE-352M standard superimposed on the input signals. Note You can confirm the Payload ID information and the signal format status of the current monitor in “SDI Payload ID Status”...
  • Page 52 Menu Function and operation ([ ]: factory setting) Slot No Enters the option slot number. You can select from Option1 to Option4, Option1&2 or Option3&4. Adaptor and the item to be selected Option1 to Option4 • When the BKM-250TG is installed and Format is set to 3G/HD/SD-SDI Auto or 4:2:2 YPbPr 10bit, 4:4:4 YPbPr 10bit, 4:4:4 RGB 10bit, 4:4:4 YPbPr 12bit or 4:4:4 RGB 12bit of 3G-SDI •...
  • Page 53 Menu Function and operation ([ ]: factory setting) Matrix/Gamma Sets Matrix/Gamma data (transmission matrix and transmission gamma) depending on the input signal format. Matrix/Gamma data are five data in which the transmission matrix and transmission gamma have been preset and five user data in which the transmission matrix and transmission gamma can be selected respectively (see below table).
  • Page 54 Menu Function and operation ([ ]: factory setting) Sets Matrix/Gamma of the HD signal. You can select from [ITU-R BT.709], ITU-R BT.601, SMPTE 240M, xvYCC 709, xvYCC 601 or User1 to User5. Sets Matrix/Gamma of the SD signal. You can select from ITU-R BT.709, [ITU-R BT.601], SMPTE 240M, xvYCC 709, xvYCC 601 or User1 to User5.
  • Page 55 Menu Function and operation ([ ]: factory setting) RGB Range Sets the quantization range of the DVI or HDMI input signal. You can select when Format is set to DVI Video, DVI Computer or HDMI. DVI Video Sets the display mode for the DVI Video signal. Full: 0 (black level) to 255 (white level) (8bit) [Limit]: 16 (black level) to 235 (white level) (8bit) DVI Computer...

  • Page 56: Display Setting Menu

    Display Setting Menu Overview This menu is used for setting the monitor condition such as the color reproduction or frame. When Display Setting is selected, the following menu is displayed. iDisplay Setting User Matrix/Gamma Native Scan Mode: Aperture Value: NTSC Comb Filter: Filter Switch: Peak White Control: Menu Function and Operation...
  • Page 57 Menu Function and operation ([ ]: factory setting) Monitor ID Enter the ID number of the source monitor. When the NETWORK switch is set to PEER TO PEER, this is not selectable. When the ID number is entered, you can select from User1, User2, User3, User4 or User5. Memory Stick Copies data in the “Memory Stick”.

  • Page 58: Display Function Menu

    Display Function Menu Overview This menu is used to set the function related to the picture display. When Display Function is selected, the following menu is displayed. iDisplay Function Marker Setting P&P Setting Pixel Zoom Setting Black Detail Setting B Capture Internal Signal Function Switch...
  • Page 59 Menu Function and operation ([ ]: factory setting) Bright Sets the luminance of the aspect marker. You can select from [90IRE] (bright) or 40IRE (dark). Area Marker 1 Sets the area marker 1. Area Marker 1 Sets whether or not to display the area marker 1 when the MARKER button is pressed (Off or [On])*.
  • Page 60 Menu Function and operation ([ ]: factory setting) Example: Area Size 80%, Aspect Mode 16:9 or 4:3 With 16:9 Aspect Mode 16:9 Aspect Mode 4:3 With 4:3 Aspect Mode 16:9 Aspect Mode 4:3 Line Sets the thickness of the area marker 1. You can select from [Thick] (thick) or Thin (thin).
  • Page 61 Menu Function and operation ([ ]: factory setting) Other Monitor Copies data from another monitor. Monitor ID Enter the ID number of the source monitor. When the NETWORK switch is set to PEER TO PEER, this is not selectable. When the ID number is entered, you can select from Marker1, Marker2, Marker3, Marker4 or Marker5.
  • Page 62 Menu Function and operation ([ ]: factory setting) Internal Signal Selects the internal signal display. You can select from PLUGE, Gray (20% gray signal), White (100% white signal), 5 step (5 step gray scale signal), Ramp, Color Bars or Black (0% black signal). To cancel the internal signal, select one from the channel numbers 1 to 30 with the numeric buttons of the controller.
  • Page 63 Menu Function and operation ([ ]: factory setting) External Sync Sets whether or not to select external sync mode ([Off] or On) when the analog component signal or analog RGB signal format is input. When On is selected, the signal to be displayed is synchronized with the sync signal input to the SYNC connector (External Sync).
  • Page 64 Menu Function and operation ([ ]: factory setting) Marker Sets whether or not to display all markers ([Off] or On). Note The marker is not displayed in the following cases: • When the input signal has no sync signal • When the internal signal is displayed •...
  • Page 65 Menu Function and operation ([ ]: factory setting) ALM Hold Reset When the item is selected, the peak hold of the audio level meter is canceled. Notes • The ALM Hold Reset is not selected in the following cases: – When the option slot number in which the BKM-250TG is installed is not selected in Slot No of the Input Configuration menu –...

  • Page 66: System Configuration Menu

    System Configuration Menu Overview This menu is used to set the system such as the network, parallel remote control function, etc. When System Configuration is selected, the following menu is displayed. iSystem Configuration Network Parallel Remote Power On Screen Set Password Date/Time Scan Mode Skip:...
  • Page 67 SDCP/SDAP Community Sets the SDCP/SDAP community name. When the item is selected, you can enter the community name (four characters). SONY: SONY is entered as a community name. New Name: Enter a new name. SDCP Port No Sets the SDCP port number.
  • Page 68 Menu Function and operation ([ ]: factory setting) 1 Pin to 8 Pin Assigns the function to each pin of the PARALLEL REMOTE connector when Parallel Remote is set to On. 1 Pin: [CH01] 2 Pin: [CH02] 3 Pin: [External Sync] 4 Pin: [Mono] 5 Pin: [Marker] 6 Pin: [unused]...
  • Page 69 Menu Function and operation ([ ]: factory setting) Power Sets the status of the monitor when the main power is turned on or the power is turned on by remote operation. Standby Mode Sets the status when the ?/a (main power) switch is turned on. [Off]: Operation mode On: Standby mode Power On Status...
  • Page 70 Menu Function and operation ([ ]: factory setting) Type Sets the closed caption type. [Auto1]: Select to set to 608(VBI) when the SD-SDI signal is input or 708 when the HD- SDI signal is input. Auto2: Select to set to 608(VBI) when the SD-SDI signal is input or 608(708) when the HD-SDI signal is input.
  • Page 71 Menu Function and operation ([ ]: factory setting) Apply Password Sets whether or not to apply the password to each menu (Yes or [No]). Adjustment Yes: Apply the password. [No]: Not apply the password. Input Configuration Yes: Apply the password. [No]: Not apply the password.
  • Page 72 Menu Function and operation ([ ]: factory setting) FPGA Upgrade Upgrades the FPGA data of the monitor. Maintenance The menu for the Sony service representative is displayed. System Configuration Menu...

  • Page 73: File Management Menu

    File Management Menu Overview The system data is saved, copied and deleted. When File Management is selected, the following menu is displayed. iFile Management Save To Copy From Delete Data Maintenance Menu Function and Operation Menu Function and operation ([ ]: factory setting) Save To Saves the data in the “Memory Stick”.
  • Page 74 Menu Function and operation ([ ]: factory setting) Memory Stick Selects the data in the source “Memory Stick”. When the item is selected, the file names in the “Memory Stick” are displayed. When the item is selected, you can select the data to be copied. All: Copies all data.

  • Page 75: Status Menu

    Status Menu Overview This menu is used to view general data about the monitor status, current channel, etc. When Status is selected, the following menus are displayed. iStatus iStatus CH Status Model Name: xxxxx Serial No: xxxxx Slot Status Software Version: xxxxx Option1 HD-SDI/D1 Option2 D1...
  • Page 76 Menu Function and operation ([ ]: factory setting) SDI Payload ID Status Displays the information of the Payload ID data superimposed on the SDI signal and current signal status of the monitor. When the option slot number in which the BKM-250TG is installed is selected in Slot No of the Input Configuration menu, the following is displayed.

  • Page 77: Controller Menu

    Controller Menu Overview This menu is for the network setting and assigning the function to the function button of the controller. When Controller is selected, the following menu is displayed. iController Network Function Key Monitor ID Display: Controller Upgrade Menu Function and Operation Menu Function and operation ([ ]: factory setting)
  • Page 78 SDCP/SDAP Community Sets the SDCP/SDAP community name. When the item is selected, you can enter the community name (four characters). SONY: SONY is entered as a community name. New Name: Enter a new name. SDCP Port No Sets the SDCP port number.
  • Page 79 Menu Function and operation ([ ]: factory setting) F1 to F16 The following functions are assigned. Scan Mode: Changes the scan mode of the picture. Native Scan: Displays the picture in native scan mode. 16:9: Changes the aspect ratio to 16:9, and when set to Off, the aspect ratio changes to 4:3.
  • Page 80 Menu Function and operation ([ ]: factory setting) Area Marker 1: An area marker 1 is displayed on the screen. Note When External Sync is set to On, the marker may not be shown in the correct position. Area Marker 2: An area marker 2 is displayed on the screen. Note When External Sync is set to On, the marker may not be shown in the correct position.

  • Page 81: Key Protect Menu

    Key Protect Menu Overview This menu is used to lock the data so that the setting is not changed by an unauthorized user. MENU Adjustment Input Configuration Display Setting Display Function System ConfigurationB File Management Status Controller Key Protect: Menu Function and Operation Menu Function and operation ([ ]: factory setting)

  • Page 82: Selecting Display Mode

    Operations Chapter For selecting the interlace display mode, set Native Selecting Display Mode Scan (page 62) to On in the Display Function menu or by pressing the NATIVE SCAN button of the controller. This monitor applies high-contrast to the picture and Set Interlace and Black Frame Insertion in the reproduces accurate color by displaying the interlace Function Switch menu (page 62) of the Display...

  • Page 83: Setting The Display Of Native Scan Mode

    Setting the Display of Native Scan Mode Displayed the whole picture of the H direction UP button DOWN button by sliding the picture About the native scan mode with the PHASE knob of the controller. You can set the picture display type for the native scan mode according to the input signal.

  • Page 84: Selecting The Native Scan/Scan Mode

    Under Scan: Under mode Selecting the Native Over Scan: Over mode Scan/Scan Mode For details on the Function Switch menu, see “Function Switch” (page 62) in the Display Function menu. You can select scan mode from a native scan that maps the Note pixel of the signal to the panel in one to one mode, under The scan mode is not selectable in the following cases:...

  • Page 85: Displaying Two Signals On One Screen

    * The function of Picture&Picture is assigned to each function button of the controller in the Function Key menu (page 78) Displaying Two Signals of the Controller menu. on One Screen Select the channel number and set the input signal to display as signal B.

  • Page 86: Magnifying The Picture (Pixel Zoom)

    Press the ENTER (Ent) button. Magnifying the Picture Part inside the cursor is magnified. You can move the position of the magnified picture (Pixel Zoom) with the PHASE knob or CHROMA knob. You can change the magnification ratio with the UP or DOWN button.

  • Page 87: Displaying The Picture In Black Detail Mode

    To end the black detail mode Displaying the Picture in Set the Black Detail Mode button of the controller to off, or set the Black Detail Mode to Off in the Function Switch Black Detail Mode menu of the Display Function menu. Black detail mode display function You can reduce to dull black color by backlight leaking and precisely assess any parts with low color gradation.

  • Page 88: Capturing The Picture Of The Hd Signal

    To hide the characters on the monitor, set the CHAR Capturing the Picture of OFF button to on. As the characters are hidden, it becomes easy to confirm the still picture. To display the HD Signal (HD Frame the characters, set the CHAR OFF button to off. Capture) Press the ENTER (Ent) button.

  • Page 89: Displaying The Area Marker Or Aspect Marker

    Displaying the Area Displaying the Audio Marker or Aspect Marker Level Meter The monitor is equipped with two area markers and center The audio level of the embedded audio signals marker as the safe area marker and aspect marker for superimposed on the SDI signals is displayed by installing confirming the picture angle.

  • Page 90: Displaying The Time Code

    Audio level Audio level Displaying the Time Code (dB) OVER The time code superimposed on the SDI signals is displayed by installing the optional input adaptor (BKM- 250TG). Note As the time code is superimposed on the video signal, the time code may be invisible partially because of the scan mode setting of the monitor.

  • Page 91: Switching The Display Of The 3D Video Signal

    Select Checkerboard display or L/R Switch display Switching the Display of with the function button* of the controller or in the Function Switch menu of the Display Function menu, the 3D Video Signal and set it to On. If the Checkerboard or L/R Switch function has been assigned to a pin of the PARALLEL REMOTE Left (L) and right (R) 3D video signals can be displayed on connector, set Parallel Remote to On in the System...

  • Page 92: Copying The Setting Or Adjustment Value To Another

    Press the ENTER (Ent) button. Copying the Setting or The data is saved in the “Memory Stick”. Adjustment Value to Notes Another Monitor • Data saving, copying and deleting using the “Memory Stick” is not available on BKM-15R or BVM-A14F5. •...

  • Page 93: Assigning The Function On The Function Button

    • When the unit is upgraded, use the AC power Supply for B Off the monitor. Chroma Up To get the upgrade data Black Frame Insertion Contact your Sony representative. Interlace Pixel Zoom Marker Saving the Upgrade Data in a Aspect Marker “Memory Stick PRO”...

  • Page 94: Upgrading The Monitor

    “Procedure failure” is displayed in red. If this error message is displayed, contact Insert the “Memory Stick PRO” into the Memory Stick your Sony representative. insertion slot of the controller. Upgrading the Controller Select the Monitor Upgrade menu in the System Configuration menu (page 71).
  • Page 95 If this error message is displayed, It takes about 1 minute to upgrade the controller. contact your Sony representative. Exit the Controller Upgrade menu, select the REMOTE Controller Upgrade menu again, and confirm that the SINGLE version of the selected item has been upgraded.

  • Page 96: Appendixes

    Appendixes HDMI HDMI × 1 Specifications HDCP correspondence, Deep Color correspondence Signal format Refer to “HDMI” (page 107) of General “Available Signal Formats”. LCD panel a-Si TFT Active Matrix Control OPTION A: Mini-DIN 8-pin (female) × Picture size 31.55 inches Display area 698.4 (H) ×...
  • Page 97 TO RECORD CONTENT OF ANY TYPE. • Always verify that the unit is operating properly Accessories supplied before use. SONY WILL NOT BE LIABLE FOR DAMAGES OF ANY KIND INCLUDING, BUT AC power cord (1) NOT LIMITED TO, COMPENSATION OR...

  • Page 98: Input Signals And Adjustable/Setting Items

    Input Signals and Adjustable/Setting Items Input signal Analog DVI-D HDMI Item Component 3G/HD Video Computer (YPbPr) Composite YPbPr YPbPr RGB CONTRAST BRIGHT CHROMA × × × × × a (*7) PHASE × × × × × × × × × ×...
  • Page 99 Input signal Analog DVI-D HDMI Item Component 3G/HD Video Computer (YPbPr) Composite YPbPr YPbPr RGB Black Frame Insertion See “Picture·Frame Display” on page 112. Interlace Black Detail Mode (*6) Audio Level Meter × × × × × × × × ×...

  • Page 100: Available Signal Systems

    Available Signal Systems Input adaptor Total lines Active lines Frame rate Scanning Aspect Display on the Signal system Standard per frame per frame (Hz) format ratio monitor Rec.ITU-R 720×576/50i 2:1 Interlace 16:9/4:3 575/50I BT.601 1440×576/50i* 2:1 Interlace 16:9/4:3 575/50I Rec.ITU-R 480/60I 720×487/59.94i 30/1.001...
  • Page 101 *: The analog component signal or analog RGB signal from BKM-229X is processed in 720 dots × 2 (1440 dots). **: Displays when the signal is input from BKM-250TG, Format is set to 3G/HD/SD-SDI Auto (page 51) in the Input Configuration menu and the Picture Rate information of the Payload ID superimposed on the input signal is 23.98, 29.97 or 59.94.

  • Page 102: Available Signal Formats

    Available Signal Formats Input adaptor BKM- BKM- BKM- BKM- BKM- Signal format Applied system 220D 227W 229X 243HS/ 250TG Standard 244CC Analog Composite Setup NTSC 487/59.94i × × × × SMPTE-170M level 576/50i × × × × PAL-M 487/59.94i × ×...
  • Page 103 BKM- BKM- BKM- BKM- BKM- Signal format Applied system 220D 227W 229X 243HS/ 250TG Standard 244CC 1080/24*P × × × × 1080/25P × × × × SMPTE-274M 1080/30*P × × × × 720/60*P × × × × SMPTE-296M 720/50P × ×...
  • Page 104 BKM- BKM- BKM- BKM- BKM- Signal format Applied system 220D 227W 229X 243HS/ 250TG Standard 244CC Single-link 4:2:2 YPbPr 10bit × × × SMPTE-292M YPbPr 10bit 10bit 1920×1080/30*P Dual-link 4:4:4 × × × a(2) SMPTE-372M YPbPr 12bit 12bit Single-link 4:2:2 YPbPr 10bit ×...
  • Page 105 BKM- BKM- BKM- BKM- BKM- Signal format Applied system 220D 227W 229X 243HS/ 250TG Standard 244CC 4:4:4 YPbPr 10bit 4:4:4 10bit Single-link 1920×1080/30*P × × × × SMPTE-425-AB 4:4:4 YPbPr 12bit 4:4:4 12bit 4:4:4 YPbPr 10bit 4:4:4 10bit Single-link 1920×1080/50i ×...
  • Page 106 DVI-D Interface sampling Aspect Signal format System Standard frequency ratio [MHz] DVI Video Single-link 4:4:4 8bit 640 × 480/60*P 25.200* Single-link 4:4:4 8bit 720 × 480/60*P 27.027* 4:3/16:9 Single-link 4:4:4 8bit 1280 × 720/60*P 74.250* 16:9 Single-link 4:4:4 8bit 1920 × 1080/60*i 74.250* 16:9 Single-link...
  • Page 107 HDMI Interface sampling Aspect Signal format System Standard frequency ratio [MHz] HDMI 640 × 480/60*P 25.200* 720 × 480/60*P 27.027* 4:3/16:9 1280 × 720/60*P 74.250* 16:9 1920 × 1080/60*i 74.250* 16:9 720 (1440)*** × 480/60*i 27.027* 4:3/16:9 720 × 576/50P 27.000* 4:3/16:9 1280 ×...

  • Page 108: Aperture Modification Frequency

    Aperture Modification Frequency Serial digital input Analog input DVI-D/HDMI input Signal system Composite SD-SDI 3G/HD-SDI Component (YP (Y/C) Input adaptor 576/50i 5 MHz 5 MHz 5 MHz 5 MHz 487/59.94i 5 MHz 5 MHz 5 MHz 5 MHz 576/50P 10 MHz 10 MHz 483/59.94P 10 MHz...

  • Page 109: Picture Display Size

    Picture Display Size Input adaptor Native Scan Native Native Normal Aspect Under Scan Over Scan Side by Side Aspect Scan ×1 Scan ×2 Scan Signal system Correction ratio (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) ×...
  • Page 110 DVI-D Native Scan Native Native Normal Aspect Under Scan Over Scan Side by Side Aspect Scan ×1 Scan ×2 Scan Signal system Correction ratio (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) ×...
  • Page 111 HDMI Native Scan Native Native Normal Aspect Under Scan Over Scan Side by Side Aspect Scan ×1 Scan ×2 Scan Signal system Correction ratio (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) × (V) (H) ×...

  • Page 112: Picture·frame Display

    Picture·Frame Display Input adaptor Black frame Signal system Interlace Display frame rate [Hz] insertion 720 × 576/50i 1440 × 576/50i** 720 × 487/59.94i 120/1.001 1440 × 487/59.94i** 120/1.001 1440 × 576/50P** × 1440 × 483/59.94P** × 120/1.001 1920 × 1080/24*PsF ×...
  • Page 113 DVI-D Black frame Signal system Interlace Display frame rate [Hz] insertion DVI Video 640 × 480/60*P × 120* 720 × 480/60*P × 120* 1280 × 720/60*P × 120* 1920 × 1080/60*i 120* 720(1440)** × 480/60*i 120* 720 × 576/50P × 1280 ×...
  • Page 114 Black frame Signal system Interlace Display frame rate [Hz] insertion 1280 × 1024/60P (SXGA) × × 1400 × 1050/60P (SXGA+) × × * : Also compatible with 1/1.001. **: Pixel Repetition = 2 (transmit the same pixel twice) Picture·Frame Display...

  • Page 115: Matrix/Gamma Setting Table

    Matrix/Gamma Setting Table Input adaptor • M in the following table shows Matrix. • G in the following table shows Gamma. Matrix/Gamma ITU-R ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ Signal BT.709 BT.601 240M User5 Gamma Signal format system data setting SMPTE area...
  • Page 116 Matrix/Gamma ITU-R ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ Signal BT.709 BT.601 240M User5 Gamma Signal format system data setting SMPTE area Analog RGB** 1080/60*i 1080/50i 1080/24*PsF 1080/25PsF 1080/30*PsF 1080/24*P 1080/25P 1080/30*P 720/60*P 720/50P 483/59.94P 576/50P 487/59.94i 576/50i 720 × 487/ 59.94i 720 ×...
  • Page 117 Matrix/Gamma ITU-R ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ Signal BT.709 BT.601 240M User5 Gamma Signal format system data setting SMPTE area Single-link 4:2:2 YPbPr 10bit YPbPr 10bit 1920 × 1080/ RGB** 10bit 30*PsF Dual-link 4:4:4 YPbPr 12bit RGB** 12bit Single-link 4:2:2 YPbPr 10bit YPbPr 10bit 1920 ×...
  • Page 118 Matrix/Gamma ITU-R ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ Signal BT.709 BT.601 240M User5 Gamma Signal format system data setting SMPTE area 3G-SDI 4:4:4 YPbPr 10bit 4:4:4 RGB** 10bit 1920×1080/ Single-link 24*PsF 4:4:4 YPbPr 12bit 4:4:4 RGB** 12bit 4:4:4 YPbPr 10bit 4:4:4 RGB** 10bit 1920×1080/ Single-link...
  • Page 119 Matrix/Gamma ITU-R ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ Signal BT.709 BT.601 240M User5 Gamma Signal format system data setting SMPTE area 4:4:4 YPbPr 10bit 4:4:4 RGB** 10bit Single-link 1920×1080/50i 4:4:4 YPbPr 12bit 4:4:4 RGB** 12bit 4:4:4 YPbPr 10bit 4:4:4 RGB** 10bit Single-link 1920×1080/60*i 4:4:4 YPbPr 12bit...
  • Page 120 DVI-D • M in the following table shows Matrix. • G in the following table shows Gamma. Matrix/Gamma ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ ITU-R BT.709 BT.601 240M User5 Gamma Signal format System data setting SMPTE area DVI Video Single- 4:4:4 RGB** 8bit 640 ×...
  • Page 121 HDMI • M in the following table shows Matrix. • G in the following table shows Gamma***. Matrix/Gamma ITU-R SMPTE xvYCC xvYCC User1 - Matrix/ ITU-R BT.709 BT.601 240M User5 Gamma Signal format System data setting SMPTE area 240M HDMI 640 ×...

  • Page 122: Scan Mode Image

    Scan Mode Image Example: Scan images of available signal system when the input adaptor is installed For details of the picture display size, see page 109. • For setting of the Native Scan Mode menu, see Native Scan Mode (page 57) of the Display Setting menu. •...
  • Page 123 Scan mode Input signal system and scan mode image Normal Scan Aspect: 16:9 1920 × 1080 1280 × 720 720 × 576 720 × 487 1440 × 576 1440 × 487 1440 × 483 Aspect: 4:3 720 × 576 720 × 487 1440 ×...

  • Page 124: Troubleshooting

    Troubleshooting This section may help you isolate the cause of a problem and as a result, eliminate the need to contact your Sony service representative. Symptom Assumed causes Remedy The picture that you wish to The setting of the Input Configuration See the Status menu (page 75) to confirm the display is not displayed.
  • Page 125 Symptom Assumed causes Remedy The setting is different from the The setting has been changed with The last setting becomes effective. setting in the menu. the function button of the controller after setting in the menu. The function button of the The setting has been changed in the The last setting becomes effective.

  • Page 126: Dimensions

    Rear Dimensions 200 (7 Unit: mm (inches) Front 794 (31 * When using this hole, use a screw which can be inserted into the monitor to a depth of 6 to 8 mm ( inches). 270 (10 640 (25 Side 243.1 (9 139.3 Ø55 (2...

  • Page 127: Connection Cable Specifications For Color Temperature Probes

    Connection Cable Specifications for Color Temperature Probes Specified cables are required to connect color temperature The following diagrams show pin assignments to connect probes to the monitor. the supplied connection cable for color temperature adjustment and optional D-sub 9-pin connector. Connection cable for color temperature adjustment (supplied) Mini DIN 8-pin connector (male) Color of cable core...
  • Page 128 Connection cable for DK-Technologies PM 5639/06 probe D-sub 9-pin connector (male) Mini DIN 8-pin connector (male) (optional) Signal Pin number Pin number Signal Connection cable for color temperature adjustment (supplied) Connection cable for X-Rite Eye-One Pro probe D-sub 9-pin connector (female) Mini DIN 8-pin connector (male) (optional) Signal...

  • Page 129: Inserting/Ejecting The "Memory Stick

    MagicGate is copyright protection technology developed • Be sure to insert the “Memory Stick” in the correct by Sony Corporation. direction. Forcing the “Memory Stick” in the wrong way may damage it. • Insert only the “Memory Stick” into the Memory Stick insertion slot.
  • Page 130 Micro”, “M2” and are trademarks or registered • You cannot record or erase data when the write-protect trademarks of Sony Corporation. tab on the “Memory Stick” is set to LOCK. • Image data may be damaged in the following cases: Windows is a registered trademark of Microsoft –...

  • Page 131: Menu Index

    Menu Index The menu index shows the principal menu items provided manual on which the item is explained and the main menu with this monitor in alphabetical sequence. For your that the item belongs to. reference, each menu item is followed by the page of this Menu Item Page Main menu...
  • Page 132 Menu Item Page Main menu Chroma Up Display Function menu Clip Indicator Display Function menu Closed Caption System Configuration menu Color Bar Adjustment menu Color Gamut Input Configuration menu Color Temp Input Configuration menu Color Temp Adj Adjustment menu Comb Display Function menu Component Level Input Configuration menu...
  • Page 133 Menu Item Page Main menu HDMI Auto Input Configuration menu Input Configuration menu Input Configuration menu HDMI Status Status menu Input Configuration Input Configuration menu Input Information System Configuration menu Input No Input Configuration menu Interlace Display Function menu Internal Signal Display Function menu Kernel Upgrade System Configuration menu...
  • Page 134 Menu Item Page Main menu Peak White Control Display Setting menu Picture Adj Adjustment menu Picture Preset Input Configuration menu Pixel Zoom Setting Display Function menu Position Adj Adjustment menu Power System Configuration menu Power On Status System Configuration menu Preset Value Adjustment menu Adjustment menu...
  • Page 135 Menu Item Page Main menu Time Code Display Function menu System Configuration menu Transparency System Configuration menu Type System Configuration menu User Data Display Setting menu User Matrix/Gamma Display Setting menu V Delay Display Function menu V Position Display Function menu V Shift Adjustment menu VITC/LTC...
  • Page 136 The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of any...
  • Page 137 Sony Corporation PVM-L3200 (WW) © 2009 4-159-050-12(1)

Table of Contents
