GETTING TO KNOW YOUR CAMERA

7
6
5
18
ITEM
POWER ON/OFF, MODE, MENU
1
SCROLLING button
2 Slave strobe sync light
3 Video recording in progress light
4 Lock latch
5 Water repellant glass lens port
6 Lens port ring
7 SHUTTER button
8 MENU, WiFi ON/OFF, DELETE button
Port for rear video recording in
9
progress light
10 UP, ZOOM IN button
OK, Picture in video( take photos while
11
video recording) button
DOWN, ZOOM OUT, LCD ON/OFF
12
button
8
1
2
21
20
19
FUNCTION
15
3
4
14
22
23
24
17
ITEM
13 Float strap attachment point
14 Tripod mount
15 Removable anti-glare LCD hood
16 O-ring
Thumb press backdoor opening system
17
in case of vacuum; see page 5.
18 High Definition TV output port
19 Micro SD card port
20 USB port
21 Li-ion battery cover; lift to open
22 LCD screen
Rear video recording in progress
23
indicator light
24 Microphone
4
9
16
FUNCTION
10
11
12
13
