Main Function - iSolution DMX512 575W Plus User Manual

DMX On
MASTER On
SLAVE On
SOUND Flashing
Button
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
Remote controller input
By connecting to the 1/4" microphone jack to control the unit for Stand by, Function, and
Mode function.
Sensitivity
To adjust the sound-receiving sensitivity .
DMX input/output
For DMX 512 link, use 3-pin XLR plug cable to link the unit together.

4.2. Main Function

To select any of the pre-set functions, press the MENU button up to when the required one
is shown on the display. Select the function by ENTER button and the display will blink. Use
DOWN and UP button to change the mode. Once the required mode has been selected,
press the ENTER button to setup or it will automatically return to the main functions without
any change after idling 8 seconds. To go back to the functions without any change press the
MENU button. The main functions are shown below:
DMX input present
Master mode
Slave mode
Sound activation
8C
DMX 512 Address Setting
Press the MENU button up to when the
button and the display will blink. Use DOWN and UP button to change the DMX512 address.
Once the address has been selected, press the ENTER button to setup or automatically
return to the main functions without any change after 8 seconds. To go back to the functions
without any change press the MENU button again.
Channel Mode
Press the MENU button up to when the
Pressing ENTER button and the display will blink. Use DOWN and UP button
to select the (16 Channel ) or
mode has been selected, press the ENTER button to setup or automatically
return to the main functions without any change after 8 seconds. To go back to
is shown on the display. Pressing ENTER
is shown on the display.
(8 Channel) mode. Once the
9C
