iSolution ic3000 User Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Enlarged version
User Guide
Professional Entertainment Technology
INDEX
1. General Instructions
2. Main Features
3. Lamp
4. How To Set The Unit
4.1 Control Panel
4.2 Main Function
5. How To Control The Unit
A. By master/slave preprogrammed function
B. By easy controller
C. By Colormix controller
D. By universal DMX controller
6. DMX Linking & Controls
7. Troubleshooting
8. Fixture Cleaning
1 A

Advertisement

loading
Need help?

Need help?

Do you have a question about the ic3000 and is the answer not in the manual?

Questions and answers

Related Manuals for iSolution ic3000

Summary of Contents for iSolution ic3000

  • Page 1 INDEX 1. General Instructions 2. Main Features 3. Lamp 4. How To Set The Unit 4.1 Control Panel 4.2 Main Function 5. How To Control The Unit A. By master/slave preprogrammed function B. By easy controller C. By Colormix controller D.
  • Page 2 1. General Instructions 2. Main Features The following points are important for safety as well as for the smooth installation and Voltage：AC 120V 60Hz or 230/240/250V 50/60 Hz • Bulb： J Type 230V 800W(Euro) performance of the unit. J Type 120V 500W(USA) •...
  • Page 3 4. How To Set The Unit 4. 2 Main Function To select any of the given functions, press the MENU button up to when the required one is 4.1 Control Panel showing on the display. Select the function by ENTER button and the display will blink. Use DOWN and UP button to change the mode.
  • Page 4 Blackout Mode Fixture Hours Press the MENU button up to when the is showing on the display. Pressing Press the MENU button up to when the is blinking on the display. Pressing ENTER ENTER button and the display will blink. Use DOWN and UP button to select the button and the display will show the number of working hours of the unit.
  • Page 5 C. By Colormix controller D. By universal DMX controller By link the Colormix controler to the unit , you have to use 3 pin XLR cable and use 5 If you use a universal DMX controller to control the units, you have to set DMX address from pin XLR cable between Colormix controller and Colormix foot controller.
  • Page 6 • DMX512 Configuration 6. DMX Link & Controls You can select 4 or 3 channels mode. 4 channels: 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.
  • Page 7 7.Troubleshooting 8. Fixture Cleaning Following are a few common problems that you might encounter, and suggestions The cleaning of internal and external optical lenses and/or mirrors must be carried out as to how to solve them. periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater A.
  • Page 8 Technical Specifications Power AC 120V 60Hz AC 230/240/250V 50/60Hz Fuse 6X30mm Glass T15A Lamps J Type 120V 500W J Type 230V 800W Dimension 295mm x 285mm x 460mm Weight 8.8 kg / 19.6 lbs Innovation , Quality , Performance 14 A 15 A...
