ACCESSORIES AND ATTACHMENTS

RECOMMENDED ACCESSORIES
WARNING
Visit your Hardware Department or see the Power
and Hand Tools Catalog to purchase recommended
accessories for this power tool.

TOOLS NEEDED FOR ASSEMBLY

Supplied
Hex Wrench
Hex Wrench
Hex Wrench
UNPACKING AND CHECKING CONTENTS
Separate all parts from packing materials. Check each
part with the illustration on the next page and the "Table
of Loose Parts" to make certain all items are accounted
for, before discarding any packing material.
TABLE OF LOOSE PARTS
ITEM DESCRIPTION
A
Table saw assembly
B
Table extension
L-shape rod, hex wrench, blade
C
wrench
D
Support bracket (Short)
E
Support bracket (Long)
F
Adjustable rod
G
Table extension hardware bag
H
Rip fence (Short)
I
Rip fence (Long)
J
Mitre gauge
K
Dust extraction port hardware bag
Push-stick and blade wrench
L
storage hardware bag
M
Upper blade guard
N
Upper blade guard hardware bag
O
Push stick
Not Supplied
Medium Screwdriver
#2 Phillips Screwdriver
Straight Edge

CARTON CONTENTS

QUANTITY
1
1
1each
2
2
1
1
1
1
1
1
1
1
1
1
– 7 –
WARNING
To avoid the risk of personal injury:
● Do not use molding head set with this saw.
● Do not modify this power tool or use accessories
not recommended by Store.
Adjustable Wrench
Combination Square
P
Dust hose
Q
Carrying handle
R
Carrying handle hardware bag
S
Extra bracket
T
Foot pad
U
Long bracket
V
Short bracket
W
Stand leg
X
Caster
Y
Caster hardware bag
Z
Stand hardware bag
AA Dust hose clip hardware bag
WARNING
If any part is missing or damaged, do not attempt
to assemble the table saw, plug in the power cord,
or turn the switch ON until the missing or damaged
part is obtained and is installed correctly.
NOTE: To make assembly easier, keep contents of box
together. Apply a coat of automobile wax to the table.
Wipe all parts thoroughly with a clean dry cloth. This will
reduce friction when pushing the workpiece.
