Product Specification

W (mm)
1705
16:9
LF-
VMF
-77
77 "
1771
LF-
VMF
-80
80 "
2037
LF-
VMF
-92
92 "
2214
LF-
VMF
-100
100"
LF-
VMF
-106
106"
2346
LF-
VMF
-120
120"
2656
Note:
1. Due to product updates, sizes and specifications are subject to change at any time. The tolerance for L is approximately ± 5mm (3/16 inches).
2. Actual dimension is measured by: total screen length x end cap depth x end cap height.
L
H
W
Front View
Questions & Answers
Fabrics of Grandview screen can be used for years, most problems are caused by simple incidents. If problem
occurs, please find the list below for some common solutions. If problems keep on, please contact authorized
agent of Grandview or call service number at: (8620)34806166
Wrinkle on the frame
When using normally, the wrinkle can be removed naturally. The removing
period will change with 1-15days according to the temperature. Watering
can remove the wrinkle faster.
Three years warranty
Grandview provides three years warranty. Contents of warranty include replacement of spare parts while problems
occur with correct operation. Not include inappropriately operating the screen or uninstall the screen by yourself.
You should reserve in advance for the repair with Grandview or appointed service center.
Screen Size
H (mm)
L (mm)
A (mm)
958
1915
1258
996
1981
1296
1145
2247
1445
1245
2424
1545
1320
2556
1620
1494
2866
1794
60mm
A
A
60mm
60mm
110mm
38.5mm
Concave Frame
Side Frame Bar
Side View
Bar Side View
Side View
7
REPRODUCING GENUINE COLORS
105mm
Model:
Before use, please read instructions carefully. After installation, store instructions for future reference.
Large-Flat Series Adjustable Fixed-Frame Screen
LF-
VMF-xxx
Thank you for purchasing a Grandview projection screen.
Instruction Manual for

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LF-VMF-77 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grandview LF-VMF-77

  • Page 1 Side View Questions & Answers Fabrics of Grandview screen can be used for years, most problems are caused by simple incidents. If problem occurs, please find the list below for some common solutions. If problems keep on, please contact authorized...
  • Page 2 Please follow the installation as below: Caution a.Wood wall installation: fix the top and low bracket on the wall using the 5X60mm wood screw (3 screws on each bracket) (figure 11). b.Concrete wall installation: drill six proper holes on the concrete wall with electric drill, then fix the top and low bracket on the wall using the 5X40mm tapping screw and then fasten with the anchor (3 screws on each bracket) Warnings:...
  • Page 3: Screen Installation

    Screen Installation Description 1.Each screen has a set of bracket. Each bracket has a number of corresponding holes and 3 holes per group, Concave Frame Bar Please refer to figure 8. Top Bracket Side View Side Frame Bar Front View 幕布...
  • Page 4 Screen Fabric Installation Installation 1.Put the whole frame upside down and then unwrap the screen fabric (avoid scraping the fabric when Open the packing box, check whether the components which need to be installed are complete or not according to unwrapping) (figure 4).
