Grandview Legacy Series Product Manual

Ordinary electric screen (M) manual control mode:

S cr e e n ma nua l c ontrol s witc h (F igure 1 )
Open the screen (Fig. 2): Press the " " position of the control switch, the
screen will automatically drop, and the lower limit will stop automatically.
Retract the screen (Fig. 3): Press the " " position of the control switch, the
screen will be automatically recycled, and the upper limit will stop automatically.
Stop the screen operation: To stop the screen operation, place the control
switch at the center point " " and the screen stops.
Opening screen
Figure 1 Figure 2
Screen retracted
(black wire)
K 1
Common
(blue wire)
A C 22 0 ~230 V
Screen
50 ~60H z ,10 0 W deployment
(brown wire)
Yellow green
A djus tme nt me thod for scr e e n re c ove ry he ight (uppe r limit pos ition) a nd
unfolding he ight (lowe r limit pos ition):
If it is ne c e s s a ry to a djus t the limit he ight due to the ins ta lla tion e nvironme nt or the
limita tions of the s ite .
T he upper a nd lowe r limits c a n be a djus ted by a djusting the motor pos itione r insi de
the lower left of the sc re en by the motor pos itioning a djustme nt tool. A s sh own be low:
No te : W he n the scr e e n re c ove ry he ight is a djus te d be yond the uppe r limit, the scr e e n
will a utoma tic a lly drop. In this c a s e , ple a s e pre s s s top (c a n be c ontrolle d by ma nua l /
tra ns mitte r), a nd the gre e n knob c a n be rota te d c lock wis e to fine tune .
Green knob
Recover y height (upper limit)
Screen upper
Clockwise adjustment:
and lower limit
move down
adjustment
Counterclockwise adjustment:
position
move up
Yellow knob
Expand height (lower limit)
Counterclockwise adjustment:
move up
Screen upper limit switch
Clockwise adjustment:
move down
N ote:
P lea s e be c a reful. W he n a djusting the re c ove ry he ight, prevent the sc ree n from being
c a ught too muc h a nd c a us e the motor a nd s cr ee n to be da ma ged. W he n ad justing the
unfolding he ight, the height of the bla c k edge on the s c ree n c a n only be inc rea s e d
within 10c m, othe rwis e the sc ree n will fa ll off ea si ly;
E lectric a l Sc reen pa ram e ters :
volta ge A C2 20- 230V /50-6 0H z , cur rent 0. 5A , power 10 0W .
RF remote (F): Voltage 3V, use CR2032*2 battery;
Radio Freqency: 868MHz
IR remote : Voltage 3V, use CR2032 battery

Maintainance

In order to maintain good performance of screen, please
Retract screen
cover the screen with cloth if it is not used for a long term
Figure 3
to prevent dust and dirt from screen. If there are apparent
varias or dirt on screen material, please use soft brush or
cloth to clean it.
M
Clean the screen material
Rub gently according to grain of velvet frame with warm
water mixed with soft detergent. (Please be noted that it
should be gently rubbed instead of scrubbing hard).
Please prevent from hitting the frame in case of damage
of velvet. By finishing cleaning, let frames dr y itself.
Please do not use any dissolvent, chemical agent or any
tool with strong friction for clean, which would cause
permanent damage to the screen.
Motor
GRANDVIEW CRYSTAL SCREEN CO., LTD.
Add: No. 43 South International Trade Avenue, Hualong
Town, Panyu, Guangzhou, GuangDong, China
Tel: +86-20-84899499
Legacy Tab Tension Series Product Manual
W ire- controlled electric sc reen
Intelligent electric sc reen
Applic able Model：
L E - M
L E - MI
L E - MF
