TROUBLESHOOTING

When troubleshooting, always observe the charging indicators in Table 4.
Charger Indicator
No indication
Single green blink
Blinking red
Steady red
Blinking Orange
Blinking green
Steady green

No Charger Indication?

1. Check that the radio with battery, or the battery alone, is inserted
correctly (refer to Step 3 of "Charging Procedure").
2. Make sure that the power cord is securely plugged into the charger and
an appropriate AC outlet and that there is power to the outlet.

Blinking RED Indicator?

1. Remove the battery from the charger, and:
a. Verify that the battery is a Motorola-authorized battery listed in Table 1
and 2. Other batteries may not charge.
b. Remove power from the battery charger and using a clean dry cloth,
clean the metal charging contacts of both the battery and the charger.
2. Power up the charger and place the battery back into the charger
pocket. If the charger indicator continues to illuminate BLINKING RED
replace the battery.
Table 4: Battery Charging Indicators
Battery is inserted incorrectly.
Successful charger power-up.
Battery is unable to charge or not making proper contact.
Battery is in rapid-charge mode.
Battery is recognized by charger but is waiting to rapid charge.
(Either the battery voltage is too low due to over-discharge, or
the battery temperature is too low or too high to allow rapid
charging. When this condition is corrected, the battery will
automatically begin rapid charging).
Additional case for new ultra-high-capacity IMPRES Lithium-
ion (Li-ion) batteries. The new batteries have capacities
exceeding 2000 mAh. After approximately 15 minutes, the LED
may go into a Flashing Red mode. Remove and reinsert to get
another over-discharge recovery period. This procedure may
need to be repeated several times.
Battery charging is tapering off (typically charged
approximately 90% or greater).
Battery is nearly charged or charged.
