UniGuard UT01 User Manual

Gps/gprs/gsm vehicle tracker
Hide thumbs Also See for UT01:
Table of Contents

Advertisement

Quick Links

Download this manual
UniGuard Technology Limited
GPS/GPRS/GSM Vehicle Tracker

User Manual

UT01
Fast to setup device online via SMS command
A000000,022,104.243.132.242,5500,1,APN
(Call your SIM provider to get correct APN)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UT01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UniGuard UT01

Summary of Contents for UniGuard UT01

  • Page 1: User Manual

    UniGuard Technology Limited GPS/GPRS/GSM Vehicle Tracker User Manual UT01 Fast to setup device online via SMS command A000000,022,104.243.132.242,5500,1,APN (Call your SIM provider to get correct APN)

  • Page 2: System Function Introduction

    UniGuard Technology Limited 1 System Function Introduction This v e h i c l e t r a c k e r h a s c o m b i n e d GPS and GSM（GPRS） functions. Location information will be send by SMS or GPRS. You can enquiry where the vehicle is on Google map and its history.

  • Page 3: Product Description

    UniGuard Technology Limited 2 Product Description 2.1 Specification GSM module:  Band:850/900/1800/1900MHz  Max RF Output: 33.0dBm±2dBm  Dynamic Input Range: -15 ~ -102dBm GPS module:  GPS chip set: SiRF Star III  Frequency: L1, 1575.42 MHz  Number of Channel: 20 Battery: ...

  • Page 4: Installation Instructions

    UniGuard Technology Limited  Li-ion: 450mAh Input Voltage: DC 6~36V Operating Temperature:-45~65 ℃ 2.2 Features: 1. Use Google map, Global free 2. Real-time locating / inquiry 3. SOS button/Power-cut Alarm 4. Listen by telephone 5. E-fence/Over-speed Alarm 6. Compatible original anti-theft 7.
  • Page 5 UniGuard Technology Limited Description Description DC+ (6~36V) Extend port0 SOS button Extend port1 Extend port2 Engine cut_off control Extend port3 The other side PHONE LED1 LED2 Reset 1、SIM: Port for SIM card 2、PHONE: Connect to Microphone 3、MIC: Connect to earphone 4、LED1: Power light...

  • Page 6: Installation Figure

    UniGuard Technology Limited 3.2 Installation Figure pOff DC（12V） Extern Port blue blue Oil Line Oil Line DC(12V) 3.3 Installation and Test: Please test after installation. If you don’t need some functions, you can disconnect corresponding interface. Please make sure ACC, DC, GND installed correctly.
  • Page 7 UniGuard Technology Limited  LED2 is on which indicates work successfully that GSM has registered and GPS has obtained the orientation.  If LED 2 is on 0.1 second then off 0.1 second for more than 3 minutes, please make sure SIM card inserts well. Without SIM card, the device cannot work.

  • Page 8: Change Password

    UniGuard Technology Limited 4.2 Change Password (001) Message format: A******,001,New Password e.g. A000000,001,123456 Note:000000 is the old password ,123456 is the new password. Reply: Set Password OK! 4.3 Real-time return setting (002) Message format: A******,002,XXX XXX=0 is for STOP, value of XXX is within [15~64800] seconds.
  • Page 9 UniGuard Technology Limited 17:38:30, If you dial with your listen number, it can be connected automatically after the 7 ring. Then you can listen the voice in the vehicle. 4.5 Over-speed Alarm Setting (005) Message format: A******,005,XXX XXX=[000,200] (unit: km/h)XXX=00 is close the function.
  • Page 10 UniGuard Technology Limited X=0 cut off engine, x=1 resume engine, For security, this command will execute when the speed less than 20Km / h or the ACC is off. e.g. A000000,007,0 GPRS Communication Settings 5.1 Set APN (APN(Access Point NAME)) Message format: A******,012,APN Length of APN is limited within 100 characters, E.g:A000000,012,cmnet...

  • Page 11: Query The Gprs Setting

    UniGuard Technology Limited 5.4 Query the GPRS Setting If the device can not be see on the internet, you will check the APN/IP/PORT and the GPRS function of SIM card. You can send message to check the GPRS setting. Message format: A******,004 The device will send back GPRS setting parameters.

  • Page 12: User Login

    UniGuard Technology Limited GPS tracking system on website 6.1 User Login Google Map can support many different languages. It can change language for local language by itself. 6.2 Vehicle monitoring Choose vehicle in the vehicle list on the left. Then right-click, it will show a menu.
  • Page 13 UniGuard Technology Limited 6.3 Vehicle real-time tracking 1 choose vehicle 2 map mode  3.vehicle state, Google map have 3 model: map mode, satellitic mode and Hybrid mode Map mode satellites mode: www.uniguardgps.com...
  • Page 14 UniGuard Technology Limited 6.4 Vehicle history record playback Please point run history review page 1 choose vehicle 2 start time  3 inquire time  4.setup review speed 5 start review process you can know that time date , speed , way and distance sum.
