Page 1: User Manual
UniGuard Technology Limited GPS Mini Vehicle Tracker User Manual UM02 Fast to setup device online via SMS command A000000,022,104.243.132.242,5200,1,APN (Call your SIM provider to get correct APN) www.uniguardgps.com... -
Page 2: Product Instructions
UniGuard Technology Limited 1 Product Instructions It is a mini GPS Tracker, built-in GPS Antenna and GSM Antenna, Size: 48*60*22mm, Weight: 120g, it can send vehicle location and status to mobile and Internet. It can track the vehicles remotely. Tracker the vehicle on the Internet and Mobile. - Page 3 UniGuard Technology Limited 1.1 Interface 1、SIM: Port for SIM card 2、LED: Status light 3、DC+ connect to + of battery ACC connect to Ignition Line pOff connect to Relay to control Engine of auto GND connect to – of battery www.uniguardgps.com...
- Page 4 UniGuard Technology Limited 1.2 Installation Figure Please test after installation. If you don’t need some functions. Please make sure ACC, DC+, GND installed correctly. Otherwise, the device cannot work. Please check the device status through signal light after power on: ...
- Page 5 UniGuard Technology Limited 2.1 Location Enquiry (000) Message format: A******,000 e.g. A000000,000 Reply: http://maps.google.com/maps?q=-26.25613,28.11668 date:13-09-11 13:25:20,speed:0 2.2 Change Password (001) Message format：A******,001,New Password e.g. A000000,001,123456 Note:000000 is the old password ,123456 is the new password. Reply：Set Password OK! 2.3 Real-time return setting (002) Message format：A******,002,XXX...
- Page 6 UniGuard Technology Limited 2.4 Alarm Number setting Message format：A******,003,1,TelNumber e.g. A000000,003,1,136xxxxxxxx Message replied after successful setting：Set Telephone OK! 2.5 Over-speed Alarm Setting (005) Message format： A******,005,XXX XXX= [000,200] (unit: km/h) XXX=00 is close the function. e.g. A000000,005,020 Message replied after successful setting: Set Over speed (20) KM If the vehicle is over speed you set, it will send alarm SMS to SOS mobile number.
- Page 7 UniGuard Technology Limited 2.7 Engine Cut-off Setting (007) Message format: A******,007,X X=0 cut off engine , x=1 resume engine, For security, this command will execute when the speed less than 20Km / h or the ACC is off . e.g. A000000,007,0 2.8 Sleep Mode (021)
-
Page 8: Gprs Settings
UniGuard Technology Limited 3 GPRS Settings 3.1 Set APN (APN(Access Point NAME)) Message format: A******,012,APN Length limited within characters, E.g:A000000,012,cmnet “cmnet” is the APN of China Mobile 3.2 Set the IP and Port of Gprs_Server Message format: A******,010,IP,PORT e.g. A000000,010,104.243.132.242,5200 104.243.132.242 is the IP of GPRS_server, 5200 is the port of... - Page 9 UniGuard Technology Limited A000000,011,0 3.4 Query the GPRS Setting Message format: A******,004 The device will send back GPRS setting parameters. You can check whether the parameter sets correctly by it. （1）Device ID （2）APN (Please contact local SIM card provider to get correct APN) （3）Server IP address...
-
Page 10: Gps Tracking System On Website
UniGuard Technology Limited 4 GPS tracking system on website User Login Google Map can support many different languages. It can change language for local language by itself. Vehicle real-time tracking 1 choose vehicle 2 map mode 3.vehicle state, Google map... - Page 11 UniGuard Technology Limited Vehicle history record playback Please point run history review page 1 choose vehicle 2 start time 3 inquire time 4.setup review speed 5 start review process you can know that time date , speed , way and distance sum.
