Quick Installation Guide
For Windows & Mac OS
Outdoor HD IP Camera
Model: FI9804W
Model: FI9805E
Model: FI9805W
V4.7
EQ980509
ShenZhen Foscam Intelligent Technology Co., Ltd
www.foscam.com

Package Contents

IP Camera
Power Adapter
Resource CD
Ethernet Cable
Mounting Bracket
Wi-Fi Antenna
(except FI9805E)
Quick Installation Guide
For Windows & Mac OS
Outdoor HD IP Camera
Model: FI9804W
Model: FI9805W
Model: FI9805E
Quick Installation Guide
Warranty Card
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Go to the folder "IP Camera Search Tool" and find the folder "For
Windows OS"or "For Mac OS". Copy and paste the IP camera tool file
to your computer, or drag it onto your desktop.
Shortcut icon for Windows OS
Shortcut icon for Mac OS
Notes:
If your computer ( Windows OS ) supports autorun function,
you can find the corresponding file in the opened control panel.
If your computer doesn't have CD drive, you can download
the IP camera tool from our website for free.
1

Hardware Introduction

Physical Description
Antenna
LENS
Power
Infrared LED
RS485
Alarm in/out
Reset Button
Differences
PoE(Power over
Alarm
Model
Wireless
RS485
Ethernet)
in/out
FI9804W
×
×
×
FI9805W
×
×
×
FI9805E
×
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default
normally), then open the IP Camera Tool program. It should
display the camera's IP address in your LAN (Local Area Network).
2. Double click the camera list here, and your default browser will
open up to the camera's login page. When logging in for the first
time, you will need to download and install the ActiveX add-on.
Take Microsoft Internet Explorer as an example. For Google
Chrome, Apple Safari, or Mozilla Firefox, please refer to the User
Manual.
Note
Doesn't support 64-bit browser.
Hardware Connection
WPS
LAN
1. Mount the antenna and make it stand vertically(Only for the
Audio in/out
device with external antenna).
2. Connect the camera to the LAN network (Router or Switch)
via network cable.
3. Connect the power adapter to the camera.
3. After installing the add-on, refresh the browser and
click Login.
4. When setting up your camera for the first time, it will request
that you modify the default username and/or password if both
are still set to default. Input the new username and password,
click "Modify" to complete the modification. You will now use
the new username and password to log in to the camera in the
Click Install
Default user is admin with no
password.
Main stream offers the highest
quality video while Sub stream
offers less quality, but also less
delay when viewing.
Input the new username,
new password and
confirm the password.
