Foscam FI9804W Quick Installation Manual

Quick Installation Guide

（For Windows & Mac OS）
Outdoor HD IP Camera
Model: FI9804W
Model: FI9805E
Model: FI9805W
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Go to the folder "IP Camera Seach Tool" and find the folder "For
Windows OS"or "For Mac OS".. Copy and paste the IP camera tool file
to your computer, or drag it onto your Desktop.
Shortcut icon for Windows OS
Shortcut icon for Mac OS
Note:
If your computer doesn't have CD drive, you can download the
IP camera tool from our website for free.

Package Contents

IP Camera
Power Adapter
Ethernet Cable Mounting Bracket
Quick Installation Guide
（For Windows & Mac OS）
Outdoor HD IP Camera
Model: FI9804W
Model: FI9805W Model: FI9805E
Quick Installation Guide
V4.3
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default
normally), then open the IP Camera Tool program. It should display
the camera's IP address in your LAN (Local Area Network).
FI9805W
2. Double click the camera list here, and your default browser will
open up to the camera's login page. When logging in for the first
time, you will need to download and install the ActiveX add-on.
Take Microsoft Internet Explorer as an example. For Google
Chrome, Apple Safari, or Mozilla Firefox, please refer to the User
Manual.
Note：
Doesn't support 64-bit browser.
1
Hardware Introduction
Physical Description
Resource CD
LENS
Infrared LED
Model
FI9804W
FI9805W
FI9805E
Wi-Fi Antenna
Hardware Connection
1. Mount the antenna and make it stand vertically.
Warranty Card
2. Connect the camera to the LAN network (Router or Switch)
via network cable.
3. Connect the power adapter to the camera.
3. After installing the ActiveX add-on, refresh the browser
and click Login.
4. After logging in, you should see live video on the interface.
Click Install
Antenna
LAN
Audio in/out
Power
RS485
Alarm in/out
Reset Button
Differences
PoE(Power over
Alarm
Wireless RS485
Ethernet) in/out
√ × × ×
√ × × ×
× √ √ √
WPS
Default user is admin with no
password
Main stream offers the highest
quality video while Sub stream
offers less quality, but also less
delay when viewing.
