- Page 1 SB-5450 4x2 Composite/S-Video/Audio Matrix Routing Switcher (IR) SB-5450M...
-
Page 2: Safety Information
SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit. - Page 3 Composite Video/S-Video Matrix Switcher Series Thank you for purchasing the SB-5450 / SB-5450M Composite Video/S-Video Matrix Switcher. You will find this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use this switcher.
-
Page 4: Features And Specifications
FEATURES & SPECIFICATIONS FEATURES • Switches S-Video, Composite Video and Analog Audio between multiple sources and displays • If the input signal is Composite, the output is Composite. If the input is S-Video, the output is S-Video • Allows connection of (4) sources and (2) displays •... -
Page 5: Typical Hookup And Operation
TYPICAL HOOKUP AND OPERATION SB-5450 Front View: Rear View: Power SW : ON/OFF Input : 4x Composite/S-Video/Audio IR : Remote Controler receiver Output: 2x Composite/S-Video/Audio Video Select Buttons Power DC Input : DC12V@ 210mA Safeguards and Precautions A. Keep this unit away from fire, extremely hot areas, water or moisture of any kind. -
Page 6: Limited Warranty
LIMITED WARRANTY PLEASE READ THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTWARE PROVIDED BY, THROUGH OR UNDER SHINYBOWUSA, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to SHINYBOWUSA, Inc. - Page 7 THIS PAGE IS INTENTIONALLY LEFT BLANK.
- Page 8 122 Rose Ln. Suite 303 | Frisco, Texas 75034 1-877-SHINY-USA 1-877-744-6987 1-972-377-2508 sales@shinybowusa.com www.shinybowusa.com...
