MAINTENANCE WORK ON CHASSIS AND ENGINE
Refitting the headlight mask with the headlight (EXC-R EU, EXC-R AUS/UK, EXC-R SIX DAYS, EXC-R USA,
XCR-W ZA)

Dismount the start number plate (XCR-W USA)

Fitting the start number plate (XCR-W USA)

Handlebar position

A 0 0 A A 0 0 A
B 0 0 B
Check parts for damage and wear. Replace damaged or worn parts.
Connect the electric plug connector
500156-11
Position the headlight mask and fix it with the rubber band
Info
Take care with the contact of the holding lug at the fender.
Position the brake line and cable harness. Put the clamp on, mount and tighten
screw .
Check the headlamp setting.
500155-11
Remove screw
Remove screw
500101-10
Check parts for damage and wear. Replace damaged or worn parts.
Position the start number plate. Fit and tighten screw
Specification
Remaining screws, chassis
Info
Take care with the contact of the holding lug at the fender.
Position the brake line and cable harness. Put the clamp on, mount and tighten
500101-11
screw .
On the upper triple clamp, there are 2 holes at a distance of
Distance between holes
The holes on the handlebar support are placed at a distance of
Distance between holes
B 0 0 B
The handlebar supports can be mounted in 4 different positions.
(EXC-R SIX DAYS)
The handlebar supports can also be mounted at 2 different heights (with and with-
out spacer).
400223-11
Thick spacer
.
and take off clamp.
with distance bushing. Remove the start number plate.
M6
15 mm (0.59 in)
3.5 mm (0.138 in)
9 mm (0.35 in)
47
.
with distance bushing.
10 Nm (7.4 lbf ft)
to each other.
from the center.
