OPERATING ELEMENTS

Flasher switch (EXC-R EU, EXC-R AUS/UK)

Flasher switch (EXC-R USA)

Overview of indicator lamps (EXC-R EU, EXC-R AUS/UK, EXC-R USA)

Overview of indicator lamps (EXC-R SIX DAYS)

Speedometer

The flasher switch
Possible states
Flasher light off
Flasher light, left, on
Flasher light, right, on
500145-10
The flasher switch
Possible states
Flasher light off
Flasher light, left, on
switch returns automatically to the central position after use.
Flasher light, right, on
switch returns automatically to the central position after use.
To switch off the flasher light, press the flasher switch towards the switch case.
500142-12
Possible states
High beam indicator lamp lights up blue
Flasher indicator lamp flashes green
500147-01
Possible states
High beam indicator lamp lights up blue
500160-01
Press the key
Press the key "+" to control different functions.
Press the key " " to control different functions.
Info
In its condition at delivery, the disply mode SPEED/H and SPEED/ODO is acti-
vated.
400312-01
is fitted on the left side of the handlebar.
Flasher switch is in the central position.
Flasher switch turned to the left.
Flasher switch turned to the right.
is fitted on the left side of the handlebar.
Flasher switch pressed to the right. The flasher
Flasher switch pressed to the right. The flasher
to change the display mode or change to one of the setup menus.
High beam is switched on.
Flasher light is switched on.
High beam is switched on.
13
