MDB Family 5971 Crib Assembly And Operation Manual page 9

Conversion Rails (5789-Sold Separately) Assembly Instructions
* For all 4 in 1 cribs, please contact a retailer to order your full size adult wooden bed rails for
Congratulations on purchasing an MDB Family product. This product will provide many years of service
if you adhere to the following guidelines for assembly, maintenance and operation. This product is for
residential use only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for assem-
bling the product in addition to the Allen wrench included in the hardware box. Do not use power screw-
drivers. All of our products are made from natural woods. Please understand that natural woods have
color variations which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARD-
WARE. YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLISTIC
VARIATIONS.
C. 3/4" Flat head
screw (10)
STEP 1.
Remove the crib sides, spring frame and
post brackets.
STEP 2.
Use the Allen head bolts (D) to attach the
Left (E) and Right (F) brackets to the foot
board posts. Right post and bracket are
shown.
STEP 3.
Attach the rails to the brackets with the screws (C)
and tighten securely with a Phillips head
Screwdriver.
your full size bed conversion.
D. 3/4" Allen
head bolt (4)
HARDWARE
E. Left
bracket
STEP 4.
Attach the rails to the headboard with the
barrel nuts and bolts you removed in step 1.
Tools Needed
(not included)
F. Right
bracket
Phillips
screwdriver
Page 9
