Attach side panels to back panel.

STEP 3.
Do not overtighten the bolts.

Attach side top rails to side panels.

STEP 4.
Outside

Attach spring frame.

STEP 5.
Swing out four hangers at corner of
the spring frame (M) carefully.
Attach spring frame FLAT SIDE
UP.
Choose the height of the spring
frame. Start at the highest level
and adjust accordingly.
Bolt the spring frame (M) to head-
boards using Allen head bolts (T),
washers (S), lock washers (AA)
and Allen wrench (Z). As the child
grows, it is important to lower the
spring.
Make sure the spring frame is
level.
Do not overtighten the bolts.
Left side
panel
Do not overtighten the bolts.
F-1
AA
C-1
AA
P
P P
M
Back panel
AA
AA
F-2
AA
C-2
AA
P
P
T
Q
Right side
panel
Outside
* Make sure the support
frame is installed
FLAT SIDE UP.
* Make sure the
support frame is level.
AA
Q
AA
S
M
AA
T
Page 4
