Toddler bed (2990) -
Assembly and Operation Manual
Congratulations on purchasing a MDB Family product. This bed will provide many years of service if you adhere to
the following guidelines for assembly, maintenance and operation. This bed is for residential use only.
Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for the assembling of
the bed. Do not use power screwdrivers. All of our toddler beds are made from natural woods. Please understand
that natural woods have color variations which are the result of nature and are not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARDWARE.
YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLISTIC VARIATIONS.
Please read the Caution and Warning
Statements insert before using your bed.
page 1
revised 29DEC2011

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2990 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MDB Family 2990

Summary of Contents for MDB Family 2990

  • Page 1 Toddler bed (2990) - Assembly and Operation Manual Congratulations on purchasing a MDB Family product. This bed will provide many years of service if you adhere to the following guidelines for assembly, maintenance and operation. This bed is for residential use only.
  • Page 2 PARTS C. Slats (10) D. Center slat A. Headboard B. Footboard E. Left side rail F. Right side rail HARDWARE G. 2” Allen head bolt (4) H. Barrel nut (14) K. Allen wrench L. Lock washer (10) J. 3 1/2” Allen head bolt (10) WARNING: READ ALL INSTRUCTIONS BEFORE ASSEMBLING BED.
  • Page 3 STEP 1. Fit the dowels of the slats (C) into the pre-drilled holes of the left side rail (E). Attach the center slat (D) to the left side rail (E) using two 2” Allen head bolts (G) and two barrel nuts (H). STEP 2.

  • Page 4: Sample Label

    STEP 3. STEP 3. Connect the headboard (A) to the Connect the headboard (A) to the assembled bed frame using six assembled bed frame using six 3 1/2” Allen head bolts (J), lock 3 1/2” Allen head bolts (J), lock washers (L) and barrel nuts (H).
  • Page 5 WWW.THEMDBFAMILY.COM Care and Cleaning: OR YOU CAN CONTACT US BY MAIL: MDB FAMILY • Do not scratch or chip the finish. Do not use abrasive chemi- 855 WASHINGTON BLVD. cals for cleaning. Clean with mild soap on a soft rag. Rinse and MONTEBELLO, CA 90640 dry thoroughly.
