UNAVi ENB-X2 Installation Manual

Buick lacrosse 2010-2012 in-dash navigation diy installation guide
Hide thumbs Also See for ENB-X2:

Advertisement

Quick Links

Download this manual See also: Installation Manual
Buick LaCrosse In-Dash Navigation
MODEL: Buick LaCrosse 2010-2012
Information & Manual
.
CLASSFICATION
Installation Manual
Buick LaCrosse In-Dash Navigation DIY Installation Guide
DIY Installation Guide
[Standard Radio Use Only]
(Professional Use)
WWW.BUYUNAVI.COM
Copyright © 2013 UNAVI USA, Inc. All rights reserved.
.
MODEL
ENB-X2
.
DOCUMENT NO
BU No. 14
VERSION
PAGE
1
1.2
Date: 1/31/2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the ENB-X2 and is the answer not in the manual?

Questions and answers

Related Manuals for UNAVi ENB-X2

Summary of Contents for UNAVi ENB-X2

  • Page 1 PAGE Buick LaCrosse In-Dash Navigation DIY Installation Guide Buick LaCrosse In-Dash Navigation DIY Installation Guide [Standard Radio Use Only] MODEL: Buick LaCrosse 2010-2012 (Professional Use) WWW.BUYUNAVI.COM Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.

  • Page 2: Main Components

     All ground wires provided must be connected to chassis ground. MAIN COMPONENTS (Not actual size, Items shown may vary) LaCrosse fascia kit: - Fascia - Main LCD Panel w/Mounting Bracket Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 3 Audio (AUX) Cable w/Filter Trip Cable (pre-attached to the SD+USB int. cables) Main Cable T-Tap (22-18 Gauge) **Factory Trip Monitor Board CAN Adapter Cable Protective Cushion (Not Shown) Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.

  • Page 4: Tools Required

     Unibit*  Electrical Connectors & Tools - (Wire stripper, Crimper, T-Tap, etc.) * Required Tools Pre-installation picture of non-navigation equipped models (Trim levels may vary) Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.

  • Page 5: Gps Antenna Installation

    Once the antenna has been positioned, route the antenna cable carefully to avoid damage. Position the GPS antenna in the center of the vehicle at the highest point with a clear view of the sky. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 6 (Apply protective tapes and take care not to damage and scratch the interior dash and its related parts) Carefully pull the shift knob upwards to remove the panel assembly. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 7 (Installation is the reverse of removal) Carefully detach the center fascia panel from the dash and disconnect all plugs behind the display monitor and audio/climate control panel. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 8 Remove the 4 screws shown to remove the audio head unit. (Installation is the reverse of removal) Image of the radio chassis removed. Carefully remove all connectors behind the radio chassis. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 9 Connect the GPS antenna to the female connector labeled “GPS”. EXAMPLE ONLY It is recommended that the GPS antenna (flat side) be mounted on the upper section of the front windshield, behind the rear-view mirror. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 10 Example 2: Make sure the GPS receiver is mounted (rounded side up facing the sky) to a non-metallic panel. This shows positioned on top of the driver side dash panel. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 11 Buick LaCrosse In-Dash Navigation DIY Installation Guide Connect the external speaker to the female connector labeled “BUILT-IN SPEAKER”. This speaker will allow sound output from the UNAVI system when the audio is in XM/Radio/CD/MP3/Bluetooth mode. Sound output from the system will use the factory speakers under “AUX” mode only.
  • Page 12 PAGE Buick LaCrosse In-Dash Navigation DIY Installation Guide Image of the factory center fascia panel removed. Disassemble the components from the fascia panel as shown below: Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 13 PAGE Buick LaCrosse In-Dash Navigation DIY Installation Guide Removed factory components transferred to the UNAVI fascia kit. Disassemble the LCD monitor (Trip) panel components as shown. Use a flat-edged tool to release the locking clips around the LCD monitor case.
  • Page 14 Buick LaCrosse In-Dash Navigation DIY Installation Guide Carefully separate the LCD monitor case as shown. Release the black lock (upwards) and gently slide out the ribbon cable. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 15 Detach the LCD monitor board (Trip board) from the case and cover it with a protective cushion bag/pouch. Connect the CAN Adapter Cable to the factory Trip monitor plug marked above. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 16 Secure the board in a safe open area behind the dash panel. **Be careful not to damage** Connect the 3-pin Power connectors (male & female) to each other. **This connector MUST NOT be plugged into the Trip interface board** Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 17 Carefully cut open the shield wrap using a blade. Locate the Retained Accessory Power (R.A.P.) wire source – PURPLE Use T-Tap Connector to tap into the purple wire (soldering is recommended). Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 18 Locate the CAN wire on the back of the audio main harness – GREEN / LIGHT GREEN Use T-Tap Connector to tap into this green wire (soldering is recommended). Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 19 6-pin connector attached to the CAN Adapter Cable plugs into the Trip interface board as shown. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 20 3-pin Trip Cable connects with the female connector attached to the SD/USB interface cable. Place the Trip interface board behind the dash panel as shown. Use double-side tape to mount the board against the plastic panel. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 21 Use Unitbit to drill a hole (~3/4-inch) on the back wall of the glove box as (marked in white dotted circle), just wide enough for the SD/USB interface cables to slide through. **Proceed with Caution** Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 22 Size of hole should only be big enough to squeeze in/out the 3.5mm jack. You may try removing the USB/AUX assembly and notching one side to bring it out beside the port. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 23 Route the AUX cable underneath the center console from the bottom of the console tray to the dash/shifter panel opening (or vice versa) using a fish tape or pick-up tool. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 24 Connect the AUX Filter (RCA-male) to the “AUX OUT” RCA input located on the main cable. Plug factory audio cables back into the head unit as shown. Re-assemble the remaining factory components in reversed order it was removed. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 25 Check the cables are not being too tightly squeezed in the back of the audio unit. Plug in the remaining cables including the Main cable and SD/USB interface cable connectors to the back of the LCD panel as shown. Information & Manual Date: 1/31/2013 Copyright © 2013 UNAVI USA, Inc. All rights reserved.
  • Page 26 Installation Manual VERSION PAGE Buick LaCrosse In-Dash Navigation DIY Installation Guide Gently install the Unavi fascia kit into the dash. [INSTALLATION COMPLETE] For additional support and information, please visit us at www.buyunavi.com Thank you for choosing UNAVI! Information & Manual Date: 1/31/2013 Copyright ©...
