Attenuation

Sets how much each microphone is attenuated when it is closed.
• Attenuation can be set between -10dB and -80dB
NOTE: When a microphone is closed the level of that input is actually attenuated rather than muted. The level of
attenuation is adjustable by the Attenuation setting. In some noisy environments it may be more palatable to hear
some / most of the ambient mic noise all the time rather than hear the noise mute and then re-appear when
someone talks.

Auto-Mix Enables

The Auto-Mix enables matrix sets which inputs are included in the Auto-Mix. When an input is selected to be included
in the Auto-Mix an "A" will be displayed to the right of the input meter.
This matrix also sets which output buses the Auto-Mix will be outputted to.
33
AutoMix Setup Menu
Analog Inputs
Returns (Analog Input 5 and 6)
Digital Inputs
Selects which output busses the Auto-Mix
will be routed to
