11. HEADPHONE Knob / BACK Knob
• Press it to back out of a menu to the previous menu.
• Turn it to adjust headphone volume.
• Press and hold will enter user inputted data.
12. Star key
• From the any Home page, it advances to the next Home page.
• In the Bus Routing matrix and Card Mix matrix if pressed it you will add phase reverse to your cross point
options.
• In the Fader Assign matrix if pressed it will add trim to your cross point options.
• If pressed and held while powering-up, Maxx will look for new software and start the update process.
13. Fader 1 (4 total)
Each of four faders can be assigned to any channel or combination of channels, or act as a hardware trim
knob.
TM
14. Auto-Trim LED (4 total)
Indicates which fader is active for AutoTrim
15. Pre Fader Listen key
• Press to listen to Pre Fader audio from the corresponding fader.
• When in setup mode press to access the AES input setup menu for the corresponding AES inputs.
• Pressing from the Meta Data menu or Track Naming menu will open the list of presets.
16. SLT key
• Press and hold it to activate the Slate mic.
17. Power Key
• A quick press will power up Maxx.
• Press and hold for 3 seconds to power down Maxx. Release the key when the countdown reaches 1.
• When Auto-Pan is ON the power key will change the panning for the active channel.
18. MENU knob / SHIFT key
• From the Home page press it to access the Main Menu page.
NOTE: From the AES Virtual Fader meter screen or from the ENG meter screen you have to push and hold
to access the Main Menu.
• Turn it to scroll through the items in a menu.
• Press to select a menu item.
SHORTCUT: While scrolling through a parameter with a long list, pressing the MENU knob while turning it will
speed up the scroll speed by 10 times.
