Pin assignment

In the following, you will find the exact pin assignments of all
interfaces of the Vectron POS ColorTouch.
Drawer, PC keyboard, and serial RS-232 ports
drawers
PC keyboard
3
1
5 4
2
8 .
RS-232
.
Port 6
.
8 .
1
RS-232
.
Port 5
.
8 .
1
RS-232
.
Port 4
.
1 8 .
RS-232
.
Port 3
.
1 8 .
RS-232
.
Port 2
.
1 8 .
RS-232
.
Port 1
.
1
Vectron POS ColorTouch
1 +keyboard clock (5V) 5 drawer 4
2 +keyboard data (5V) 6 + 24 Volt
3 -keyboard reset
4 earth
5 +5 Volt
8 .
.
.
1
1 drawer 1
2 drawer 2
3 +24 Volt
4 drawer 3
7 n/c
8 sensor
maximum 1A
8 earth
7 n/c
6 DTR (out)
5 n/c
4 TxD (out)
3 +5 Volt
2 RxD (in)
1 DSR (in)
+5 Volt:
max. 500 mA
