DEGAUSSING COIL ATTACHMENT SPECIFICATION.
ATTACH THE
GROUNDING
STRAP FIRST.
With the degaussing coil leads centered on the bottom of the
CRT, FORM THE COIL to avoid the remote control board.
INSTALL A WIRE TIE through
the top hole in the left CRT ear.
INSTALL WIRE TIES through
the bottom hole in the left CRT ear.
For The Model 1493 Video Monitor.
Use degaussing coil part number CPS1766.
INSTALL A WIRE TIE through
the top hole in the right CRT ear.
INSTALL WIRE TIES through
the bottom hole, with the
grounding strap spring, in the
right CRT ear.
103
