2. The Sync signals may be of either polarity and separate or composite.
Hs
Sync
Source
Vs
Gnd
For composite sync, vertical and horizontal
sync lines are connected together.
3. The Power to the monitor is to be supplied by a secondary winding of an
isolation transformer.
120VAC 50Hz or 60Hz
230VAC 50HZ or 60Hz
120VAC 50Hz or 60Hz
230VAC 50HZ or 60Hz
XX93 Monitor Electrical Specification.
1.8K
.15V
1.8K
Ω,
220 2 PL
Monitor
Custom horizontal frequencies from 15KHz
to 39KHz are available upon request.
Model 1493
Min.
90VAC 145VAC
180VAC 290VAC
Power 35W
Model 2093
Min.
145VAC
90VAC
180VAC 290VAC
Power 45W
Model
High input voltage
Low input voltage
Horizontal sync pulse
Vertical sync pulse
Horizontal frequencies:
Vertical frequencies:
Model 1793
Max. Min. Max.
90VAC 145VAC
180VAC 290VAC
60W 40W 70W
Model 2793
Max. Min. Max.
90VAC 145VAC
180VAC 290VAC
75W 50W 100W
Min. Typ. Max
2.2V 3.5V 20V
-2.7V .30V .80V
4.0uS 12uS
1.5uS
65uS .5mS 1.5mS
15.5KHz 15.7KHz 15.9KHz
29.3KHz 29.6KHz 29.9KHz
31.2KHz 31.5KHz 31.8KHz
34.9KHz 35.2KHz 35.6KHz
37.5KHz 37.9KHz 38.3KHz
45Hz 50Hz 55Hz
51Hz 56Hz 61Hz
55Hz 60Hz 65Hz
65Hz 70Hz 75Hz
Model 1993
Min. Max.
90VAC 145VAC
180VAC 290VAC
45W 75W
Model 3693
Min. Max.
90VAC 145VAC
180VAC 290VAC
50W 100W
