Summary of Contents for Triner Scale 1200g High Precision Scale

  • Page 1 Userʼs Guide 1200g High Precision Scale Legal for Trade 1200g High Precision Scale Includes RS-232 interface port UG Version 1.2_12-30-13...
  • Page 2 !!!! CALIBRATION WARNING !!!! Calibration AND inspection of calibration properties is prohibited unless done so by a qualified scale technician. Triner Scale & Mfg.Co., Inc. 8411 Hacks Cross Road Olive Branch, MS 38654 (800) 238-0152 www.trinerscale.com © 2013 Triner Scale. All rights reserved.
  • Page 3: Table Of Contents

    User’s Guide | 1200g Table of Contents Introduction ............2 Specifications ............2 Set Up ...............3 Key Functions ............4 Operation............5 Zeroing the Indicated Weight.....5 Taring............5 Weigh an Item in a Container ....6 Accumulate Weights........6 View Audit & Calibration Counts....7 Adjusting the Parameters........7 Parameters Charts..........8-10 Output of the Weight ..........11 Output to a Receipt Printer ......11...
  • Page 4: Introduction

    User’s Guide | 1200g Introduction The CZ Precision balance is a highly accurate, fast and versatile general purpose balance scale. Construction includes a stainless steel weighing pan on an ABS base assembly. The keypad keys are light touch and the display is large easy to read liquid crystal (LCD).
  • Page 5: Set Up

    User’s Guide | 1200g Set Up PRECAUTIONS AND REQUIREMENTS FOR PRECISION WEIGHING Precision scales should be placed in a location that will not degrade the accuracy. Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents. Avoid unsuitable tables.
  • Page 6: Key Functions

    User’s Guide | 1200g Key Functions ZERO/ENTER ZERO: Sets zero point for all subsequent weighing. ENTER: For setting parameters or entering other functions. TARE Tares the scale. Stores the container weight in memory as a tare value, subtracts the tare value from the total/gross weight and shows the resulting net weight.
  • Page 7: Operation

    User’s Guide | 1200g Operation ZEROING THE INDICATED WEIGHT Press the ZERO key at any time to set the zero point from which all other weighing and counting is measured, within 10% of power up zero. This will usually only be necessary when the platform is empty.
  • Page 8: Weigh An Item In A Container

    User’s Guide | 1200g WEIGHING AN ITEM IN A CONTAINER To determine the weight of an item(s) in a container, first tare the empty container then place the item(s) in the container. The display will show the net weight. TO ACCUMULATE WEIGHTS 1) Place first item on the scale platform.
  • Page 9: View Audit & Calibration Counts

    User’s Guide | 1200g VIEW AUDIT & CALIBRATION COUNTS Calibration Counter Press P key during self-checking, display will show number of times scale has been calibrated. When the counter becomes full, it will start over at 0. Audit Operation Counter Press S key during self-checking, display will show number of audit operations.
  • Page 10 User’s Guide | 1200g FUNCTION PARAMETERS PARAMETER DESCRIPTION, OPTIONS F1 Unt UNITS OF WEIGHMENT THAT CAN BE DISPLAYED Note: The CZ 1200 displays weight in grams by default. Weight can be displayed in the various units listed below by pressing the UNIT key.
  • Page 11 User’s Guide | 1200g TECHNICAL PARAMETERS In parameter settings mode, press the MODE key to move through the available parameters, until “TECH” displays on the screen. Press ENTER. Pin will display. Enter S, PRINT, TARE. P1 Lin will display (the first Tech Parameter). PARAMETER DESCRIPTION P1 Lin...
  • Page 12 User’s Guide | 1200g PARAMETER DESCRIPTION P2 Con COMMUNICATION SELECT RS-232 TYPE S 232 = RS-232, S USB = USB interface SELECT OUTPUT MODE P prt = Connect with mini printer P cont = Connect with remote display or PC P auto = Connect with mini printer, auto print (auto accumulation) SELECT BAUD RATE...
  • Page 13: Output Of The Weight

    User’s Guide | 1200g Output of the Weight The weight indicated on the scale’s display can be output to: A) a compatible serial receipt printer, B) a compatible remote display, or C) a compatible PC. OUTPUT TO RECEIPT PRINTER To send the weight information from the CZ 1200 to a compatible receipt printer (required settings are based on printer specifications): 1) Connect the scale to the printer using a...
  • Page 14: Output To A Pc

    User’s Guide | 1200g OUTPUT TO A PC To send the weight information from the CZ 1200 to a PC: 1) Connect the scale to the PC using a standard DB9 null modem cable. 2) Access the Technical Parameters of the CZ 1200 scale (see the previous section “Adjusting the Parameters”).
  • Page 15: Output To A Remote Display

    User’s Guide | 1200g OUTPUT TO A REMOTE DISPLAY To send the weight information from the CZ 1200 to a remote display: 1) Connect the scale to the remote display using a standard DB9 null modem cable. 2) Access the Technical Parameters of the CZ 1200 scale (see the previous section “Adjusting the Parameters”).
  • Page 16: Error Codes

    User’s Guide | 1200g Error Codes ERROR CODE DESCRIPTION CAUSES Err 3 Calibration weight Attempt to calibrate error. with incorrect calibration weight. Err 4 Initial Zero is Weight on the pan greater than when turning the allowed (4% of scale on. maximum Excessive weight on capacity) when...
  • Page 17: Weighing Unit Conversions

    User’s Guide | 1200g Weight Codes and Conversion DISPLAY DESCRIPTION, CONVERSION TO GRAMS Net carat = 0.2g Lb = 453.59237g Ounce = 28.349523125g Dram = 1.7718451g Troy ounce = 31.1034768g Penny weight = 1.55517384g...
  • Page 18 NOTES...
  • Page 19 NOTES...
  • Page 20 Triner Scale & Manufacturing Co. Inc. 8411 Hacks Cross Road Olive Branch, MS 38654 (800) 238-0152 www.trinerscale.com...
