Triner Scale TS-70PX Installation Instructions

Rate Chip Installation

2014 Rate Chip Installation

Instructions For:
Instructions For:
Scale Model Part No.
TS-70PX.............RC001
TS-70xi ..............RC030
To install your new Rate Chip:
1. Turn the scale off and unplug
the AC adapter from the wall
outlet. If the scale is connected
to a remote device, unplug that
connection also.
2. The rate chip compartment is
located on the right side of the
scale. If equipped with a
Security Plate, remove the two
screws and set the plate aside.
Use a small flat head screw
driver and gently pry open the
plastic Rate Chip Compartment
Cover.
3. Remove the Rate Chip card by
grasping the edges and pulling
straight out.
4. Insert the new Rate Chip card.
Make sure the card is fully
inserted into the slot (the rate
card can only be installed in one
direction. If it does not fit properly,
turn it over and reinsert).
5. Replace the Rate Chip
Compartment Cover and, if
needed, the Security Plate.
6. Reconnect the AC adapter.
7. Your scale is now ready for use
with its new, updated rates.
IMPORTANT!
NEW SERVICES HAVE
BEEN ADDED!
Be sure to review the keypad
key functions on the back side
of this sheet.
Rate Chip Compartment Cover
Security Plate
(optional)
Triner Scale & Mfg. Co., Inc.
8411 Hacks Cross Road
Olive Branch, MS 38654-4010
TEL: 1-662-890-2385 or
Security Plate Screws
1-800-238-0152
