INSTALLATION

Step1: Disassemble the camera case into three parts as illustrated in Figure 1.
Step2: Locate where you want to install this camera (wall or ceiling), and drill holes on the wall or
ceiling for securing the bracket and routing the cables (if necessary).
INSTALLATION
Step1: Disassemble the camera case into three parts as illustrated in Figure 1.
Step2: Locate where you want to install this camera (wall or ceiling), and drill holes on the wall or
ceiling for securing the bracket and routing the cables (if necessary).
Base Part 1
Figure 1
4
Base Part 1
Figure 1
4
Part 2
Part 2
