Summary of Contents for Baumatic BHG300.5SS
- Page 1 BHG300.5SS BHG604.5SS/W BHG610.5SS BHG710.5SS BHG900.5SS GAS HOB User Manual for the...
- Page 2 User Manual for your Baumatic BHG300.5SS BHG604.5SS/W BHG610.5SS BHG710.5SS BHG900.5SS GAS HOB NOTE This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 3: Table Of Contents
Contents Environmental note Important safety information Specifications 8-13 Product details/specifications/dimensions: BHG300.5SS BHG604.5SS/W BHG610.5SS BHG710.5SS BHG900.5SS Electrical details Gas details Using the gas hob 14-16 Before first use The gas hob Automatic ignition with flame failure safety device Energy saving tips... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
No modifications to the appliance are permitted by Baumatic o You should not store or place flammable or highly flammable liquids/materials on top of or near the appliance. Items made... - Page 6 Safety o Baumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the applian ce at any time. During and after use, all surfaces will be hot. o If it is necessary for younger family members to be in the...
- Page 7 British Standards. Please see the specific section of this booklet that refers to installation. o Baumatic declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
-
Page 8: Specifications
Specifications – BHG300.5SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 494 mm Width: 288 mm Width: 270 mm Height: 45 mm Product specifications: o 1 x 3.00 kW rapid burner o 1 x 1.00 kW auxiliary burner o Front control operation... -
Page 9: Bhg604.5Ss/W
Specifications – BHG604.5SS/W Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 620 mm Width: 560 mm Height: 50 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o Front control operation o Enamelled pan stands o Automatic ignition... -
Page 10: Bhg610.5Ss
Specifications – BHG610.5SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 620 mm Width: 560 mm Height: 50 mm Product specifications: o 1 x 3.50 kW triple crown (wok) burner o 1 x 1.75 kW semi-rapid burners o 1 x 3.00 kW rapid burner o 1 x 1.00 kW auxiliary burner o Front control operation... -
Page 11: Bhg710.5Ss
Specifications – BHG710.5SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 720 mm Width: 560 mm Height: 50 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o 1 x 3.50 kW triple crown (wok) burner o Front control operation o Heavy duty cast iron pan stands... -
Page 12: Bhg900.5Ss
Specifications – BHG900.5SS Product dimensions: Aperture dimensions: Depth: 510 mm Depth: 480 mm Width: 909 mm Width: 840 mm Height: 50 mm Product specifications: o 1 x 3.00 kW rapid burner o 2 x 1.75 kW semi-rapid burners o 1 x 1.00 kW auxiliary burner o 1 x 3.50 kW triple crown (wok) burner o Front control operation o Heavy duty cast iron pan stands... -
Page 13: Electrical Details
Electrical details Rated Voltage: 230 Vac 50 Hz Supply Connection: 3A (double pole switched fused outlet with 3mm contact gap) Mains Supply Lead: 3 core x 1.5 mm² Gas details Connection: Rp ½ (ISO R7) Type: Natural Gas (20 mbar) Alternative LPG G30 (28-30/37 mbar) For future reference please record the following information which can be found on the rating plate and the date of purchase which can be... -
Page 14: Using The Gas Hob
Using the gas hob Before first use IMPORTANT: You should clean the hob surface (see “Cleaning and maintenance” section). The gas hob The following symbols will appear on the control panel, next to each control knob: Circle: gas off Large flame: maximum setting / ignition position Small flame: minimum setting o The minimum setting is at the end of the anti-clockwise rotation of the control knob. -
Page 15: Automatic Ignition With Flame Failure Safety Device
Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out. To ignite a burner: o Press in the control knob of the burner that you wish to light and turn it anti-clockwise to the maximum position. -
Page 16: Energy Saving Tips
Energy saving tips Burners Pan size Ø min Ø max 200 mm 320 mm Rapid 200 mm 260 mm Semi-rapid 140 mm 200 mm Auxiliary 100 mm 140 mm o The diameter of the bottom of the pan should correspond to that of the burner. -
Page 17: Cleaning
Cleaning Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process. Cleaning the hob top Any residues that are left on the hob top surface from cleaning agents will damage it. -
Page 18: Maintaining The Enamelled Pan Stands
IMPORTANT: Make sure that you reassemble the burners in the original way. Maintaining the enamelled pan stands (BHG300.5SS / BHG604.5SS/W) o IMPORTANT: Make sure that the hob surface and pan stands have cooled before you attempt to touch them. -
Page 19: Installation
Installation The installation must be carried out by a GASSAFE registered installer, in accordance with the current version of the following. o Gas Safety Regulations (Installation & Use) o Building Regulations (issued by the Department of Environment) o Building Standards (Issued Scottish Development... -
Page 20: Positioning
Positioning The adjacent furniture must be able to withstand a minimum temperature rise of 85°C above the ambient temperature of the room it is located in, during periods of use. o This appliance can be located in a kitchen, a kitchen diner or a sitting room. -
Page 21: Unpacking The Appliance
Unpacking the appliance When unpacking the appliance please check that the following items are contained within the packaging: 1 x Baumatic hob Pan stands Burner assemblies Instruction manual Warranty card Fixing screws Clamps Sealing strip LPG conversion jets Self-adhesive label for amending the gas category on the appliance’s rating plate (required if the LPG conversion jets are used). - Page 22 o Carefully turn the hob upside down and place it on a cushioned mat. o Apply the sealing strip provided around the edge of the appliance. o The protective covering must be removed from both sides. o Do not leave a gap in the sealing agent or overlap the thickness. o IMPORTANT: Do not use a silicon sealant to seal the appliance against the aperture.
-
Page 23: Gas Connection
Conversion for use on LPG and other gases must only be undertaken by a qualified person. For information on the use of other gases, please contact the Baumatic Customer Care Department. o The hob must be installed by a qualified person, in accordance... -
Page 24: Gas Safety (Installation And Use) Regulations
o If the room has a volume of less than 5m³, it will require an air vent of 100cm² (effective area). o If it is installed in a room with a volume that exceeds 11m³, then no air vent is required. o If there are any other fuel burning appliances in the same room the current edition of BS 5440: Part 2: should be consulted to determine air vent requirements. -
Page 25: Gas Adjustment (Conversion To Lpg)
o Put the gas seal into the elbow. o Fully tighten the elbow and seal onto the gas rail. o The elbow MUST be pointing in a downwards direction. o Gas pressure may be checked on a semi-rapid hob burner. Remove the appropriate injector and attach a test nipple. -
Page 26: Minimum Flow Adjustment For Hob Gas Taps
GAS TYPE PRESSURE Ø THERMAL BURNER INJECTOR CAPACITY CONSUMPTION mbar 1/100 Nominal W Triple- 3500 Natural crown gas – G20 Rapid 3000 Semi- 1750 rapid Auxiliary 1000 Triple- 3500 LPG – crown G30/G31 28-30/37 Rapid 3000 Semi- 1750 rapid Auxiliary 1000 o Reassemble all the burners carefully;... -
Page 27: Gas Tap Maintenance
o Unscrew the adjusting screw, in order to increase the gas flow or tighten the adjusting screw to decrease the gas flow. o The correct adjustment is obtained when the flame has a length of about 3 – 4 mm. o For butane/propane gas, the adjusting screw must be tightly screwed in. -
Page 28: Electrical Connection
If it becomes necessary to replace a gas tap, then you should proceed as follows: o Remove the control knobs, pan supports, burners, hob fixing screws and clamps. o Remove the hob from the worktop and remove any underside protective covers. o Disconnect the fixings holding the tap to the fascia panel and separate the assembly. -
Page 29: Replacing The Mains Supply Cable
Replacing the mains supply cable If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained from the Spares Department. The mains supply cable should be replaced in accordance with the following instructions: o Switch the appliance off at your mains supply. -
Page 30: My Appliance Isn't Working Correctly
IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Baumatic Customer Care Department on telephone number 0844 692 3605. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. -
Page 32: Contact Details
6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Customer Care Telephone 0844 692 3605 Spares Telephone 0844 692 3606 Website: www.baumatic.co.uk... - Page 36 1.008.89.0 www.baumatic.co.uk...
