2. INTRODUCTION
The KR100S is a high performance ultra-slim powered two way system designed for use with small to medium wavefront
systems, in both mobile and install applications. The KR100S includes two KL12ma powered subwoofers and 2 KR100 1mt
line array satellites.
The KL12ma features a 1000 watt 12" drive unit with magnet structure and suspension engineered for maximum linear
excursion.
The ultra-light reflex cabinet is fitted with two pocket handles and one 35mm pole mounting point for easy installation with
every satellite speaker on it. It features large area porting to reduce air noise.
array of 2" high efficiency drive units with neodymium magnet structure and suspensions engineered for maximum linear
excursion and minimum noise problems. The ultra-strong chassis ensures high resistance and durability also with hardest
work conditions. All the
control quality system.

3. VOLTAGE REQUIREMENTS

KA 10 operates safely and without audio discontinuity if the AC voltage stays within either of two operating
windows: 95-125 (voltage selector on 115 V) or 195-250 V (voltage selector on 230 V), at 50 or 60 Hz.
The device is default set to be connected to 230 V AC Power. To use the device on a 115 V AC Power you need,
before connecting it, to move the voltage selector's cover, just loosening the two screws, and to choose the correct
use voltage by the red switch. Be sure that both voltage set on the selector and AC Power have the same value .
Always close the voltage selector's cover before connecting the device to AC Power. Change the label that points
out the correct voltage in use.
USER'S MANUAL
REV.05
KR100S components are designed by K-array R&D department and custom made under K-array
CAUTION
Connecting a 115V system
!
damages to the device and serious risk for users .
The
on a 230V AC Power causes heavy
pag. 03
KR100S ultra-slim satellite features a line
115-230
ENGLISH
