SEA
OPERATOR'S MANUAL
SEA3-1100
SEA4-2000
SEA4-3000
■
■
■
89139990-7
®
For technical assistance or the dealer nearest you,
consult our web page at www.landa.com
8.913-999.0

Advertisement

Table of Contents
loading

Related Manuals for Landa SEA3-1100

Summary of Contents for Landa SEA3-1100

  • Page 1 OPERATOR’S MANUAL SEA3-1100 SEA4-2000 SEA4-3000 ■ ■ ■ 89139990-7 ® For technical assistance or the dealer nearest you, consult our web page at www.landa.com 8.913-999.0...

  • Page 3: Table Of Contents

    The model and serial numbers will be found on a decal attached to the pressure washer. You should record both serial number and date of purchase and keep in a safe place for future reference. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 4: Introduction

    (GFCI). If rated more than 250 volts, or more than TRIggeR gUN single phase this product should only be connected kICkS baCk - HOlD WITH bOTH HaNDS to a power supply receptacle protected by a GFCI. LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 5 The cleaning area should have adequate slopes and drainage to reduce the pos- sibility of a fall due to slippery RISk Of INjURy fROm fallS WHeN surfaces. USINg laDDeR. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 6: Component Identification

    Spray gun — Controls the application of water and floor. This system prevents internal pump damage. detergent onto cleaning surface with trigger device. Includes safety latch. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 7: Assembly Instructions

    Push coupler collar forward until secure. Connect the garden hose to pump water inlet. Inspect inlets. CAUTION: Do not run the pump with- out water or pump damage will result. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 8: Operating Instructions

    NOTe: High pressure nozzle must safety latch on the spray gun be inserted at end of wand to obtain high pressure. To trigger. apply soap read operator’s manual. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 9: Detergent And General Operating Instructions

    Apply safety latch to spray gun. Remove black soap nozzle from the quick coupler. Select and install the desired high pressure nozzle. NOTe: You can also stop detergent from flowing by simply removing detergent siphon tube from bottle. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 10: Shutting Down Procedures

    2. Restart pressure washer and let it run briefly (about 5 seconds) until water no longer discharges from the high pressure outlet. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 11: Troubleshooting

    Broken or weak suction or delivery Check and replace if necessary. valve spring Foreign matter in valves Check and clean if necessary. Worn bearings Check and replace if necessary. Excessive temperature of water Reduce to below 140 LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 12: Troubleshooting

    Replace coil after the timer and unloader switch have been tested. maCHINe Timer is defective Join wires 15 and 16 together on timer. WIll NOT If machine works, replace timer. TURN ON WHeN SWITCH IS pUSHeD LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 13: Preventative Maintenance

    Check pump oil level before first use. Change pump oil after first 50 hours and every month or 500 hours thereafter. Use SAE 30 weight oil. estimated Operating estimated Operating Date Oil Changed Hours Since last Date Oil Changed Hours Since last month/Day/year Oil Change month/Day/year Oil Change LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 14: Exploded View-Left Side

    VIeW-lefT SIDe model 3-1100 6, 7 6, 7 auto-Start/Stop Option 6, 7 Included 89139990-2 W/ pump LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 15 VIeW-RIgHT SIDe 89139990-3 LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 16: Exploded View Parts List

    Nut, 3/8" Whiz Loc SS 8.932-965.0 Label, Warning - Exposed (3-1100) Pulleys (4-2000, 4-3000) 8.900-832.0 Label, SEA Series Stripe 8.718-887.0 Nut, 5/16" SS 8.719-002.0 Washer, 5/16" x 1-1/4", Whiz Loc Fender SS 4 (3-1100) LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 17: Exploded View Parts List

    Nozzle, 1504, Yellow (4-3000) 8.712-347.0 Nozzle, 2504, Green (4-3000) 8.712-348.0 Nozzle, 4004, White (4-3000) 8.712-353.0 Nozzle, 0005, Red (4-20024F) 8.712-354.0 Nozzle, 1505, Yellow (4-20024F) 8.712-355.0 Nozzle, 2505, Green (4-20024F) 8.712-356.0 Nozzle, 4005, White (4-20024F) LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 18: Float Tank Option Exploded View And Parts List

    VIeW - flOaT TaNk OpTION 89139990-4 LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 19 Washer, 1/4" SAE, Black, w/remote switch option Zinc 8.903-461.0) 8.912-233.0 Lid & Hinges, Plastic 9.800-016.0 Label, Disconnect Power Float Tank Supply 8.900-832.0 Label, Stripe 9.802-810.0 Washer, 5/8" Flat SAE Zinc 8.719-011.0 Washer, 5/8" Star LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 20: Handheld Wireless Exploded View - 1 Step

    HaNDHelD WIReleSS explODeD VIeW - 1 STep 7, 18 l d W a t e I n l a t e t l e 22 25 89139990-6 LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 21: Handheld Wireless Exploded View Parts List - 1 Step

    LANCOM, -07 8.930-167.0 Label, Chemical, Wireless 9.802-514.0 Strain Relief, Small 8.706-423.0 Hanger Pipe 1" 9.802-251.0 Tube, 1/4" x 1/2" Clear Vinyl 10 ft 9.802-170.0 Nipple, 3/8" x 3/8" NPT, ST, FEM ▲ Not Shown LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 22: Handheld Wireless Exploded View - 2 Step

    HaNDHelD WIReleSS explODeD VIeW - 2 STep 10, 21 l d W a t e I n l a t e t l e 25 28 89139990-5 LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 23: Handheld Wireless Exploded View Parts List - 2 Step

    LANCOM, -07 8.930-167.0 Label, Chemical, Wireless 9.802-514.0 Strain Relief, Small 8.706-423.0 Hanger Pipe 1" 9.802-251.0 Tube, 1/4" x 1/2" Clear Vinyl 10 ft 9.802-170.0 Nipple, 3/8" x 3/8" NPT, ST, FEM ▲ Not Shown LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 24: Handheld Wireless Operating Instructions

    Chemical 2: To start chemical 2 flow, press transmit- ter button 4. The green indicator light will illuminate when chemical 2 is in use. Press button 4 again to stop chemical 2 flow. LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 25 3. Press and hold the Select button for 6-8 seconds so the yellow LED is on solid. (#7 Yellow LED lights) NOTe: This step is only completed when establishing the first transmitter communication. The receiver is now programmed to the desired transmitter. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 26: Hose And Spray Gun Assembly And Parts List

    5000 PSI, 10.4 GPM 9.802-251.0 Tube, 1/4" x 1/2", 9.802-286.0 Soap Nozzle Only, 1/8", Clear Vinyl 6 ft. Brass ▲ Not Shown See Pg. 17 for Correct Nozzles 8.739-072.0 Hose, 3/8" x 50', 2-Wire Tuff Skin LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 27: Pump Assemblies Exploded View And Parts List

    Nipple, 1/2 JIC x 3/8 MPT 9.802-048.0 Swivel, 1/2" JIC FEM, 9.802-254.0 Hose, 1/4 Push-On 20" 3/8" Male 9.802-042.0 Elbow, 1/2" JIC x 3/8", FEM 90° 1 9.802-039.0 Elbow, 1/2" JIC, x 3/8" MPT 90° 1 LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 28: Specifications

    2BK90H 8.715-593.0 25MM 9.802-403.0 7.5HP 460V/3PH/60 8.751-014.0 2BK36H 9.802-383.0 4-30024F LT5030 8.904-874.0 2BK90H 8.715-593.0 25MM 9.802-403.0 7.5HP 575V/3PH/60 8.715-106.0 2BK36H 9.802-383.0 4-30024H LT5030 8.904-874.0 2BK90H 8.715-593.0 25MM 9.802-403.0 7.5HP 208V/3PH/60 9.802-333.0 2BK36H 9.802-383.0 LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 29 1/2 AMP (1) 9.802-463.0 4-3F HX1-3/8" 9.802-401.0 BX36 (2) 8.715-697.0 8.724-268.0 8.724-303.0 9.803-668.0 1/2a(2) 9.802-462.0 1/2 Amp (1) 9.802-463.0 4-3H HX1-3/8" 9.802-401.0 BX36 (2) 8.715-697.0 8.724-276.0 8.724-305.0 9.804-556.0 1a(2) 8.933-007.0 1/2 AMP (1) 9.802-463.0 LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 30: Ld.1 Series Pump Exploded View And Parts List

    Bearing Seal See Kits Intermed. Ring 18mm 9.802-914.0 Snap Ring (4020, 3025) 9.803-955.0 Ball Bearing 9.802-926.0 Brass Plug 1/2" 9.803-956.0 Crankshaft 9.803-199.0 Copper Washer 1/2" 9.803-167.0 Crankshaft Key 9.803-946.0 Manifold Housing 9.803-957.0 Oil Dipstick LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 31 3, 4, 5, 34, 35, 36, 34, 35, 36, 3, 5, 7 3, 5, 7 11, 12, 13 INClUDeD 6, 7 6, 7, 37, 38 37, 38 NUmbeR Of CylINDeRS kIT WIll SeRVICe LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 32: Lt.1 Series Pump Exploded View And Parts List

    O-Ring Ø2.62 x 17.13 9.803-177.0 Shim See Kit Valve Assembly 9.803-181.0 Bearing Housing See Kit O-Ring Ø2.62 x 20.29 See Kit Plunger Bolt 9.802-928.0 Valve Plug See Kit Copper Spacer 9.802-943.0 Manifold Stud Bolt LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 33 NUMBER OF CYLINDERS KIT WILL SERVICE REPAIR KIT 9.802-603.0 9.802-606.0 NUMBER Complete Valve Plunger Oil Seals KIT DESCRIPTION (all pumps) (all pumps) ITEM NUMBERS 14, 15, 16 INCLUDED NUMBER OF CYLINDERS KIT WILL SERVICE LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 34: Vrt3 Unloader

    If “spike” pressure exceeds the 500 psi limit, remove the adjusting knob (Item 18) and re-adjust (lower) the nuts (Items 15) on the stem (Item 8). Re-attach the adjusting knob (Item 18), then repeat step #6. LANDA SEA • 8.913-999.0 • Rev. 6/13...

  • Page 35: Vb8 Unloader Exploded View And Parts List

    M 30 Nut (60.1290.00) 60.1704.31 M 22 Nut 29.0096.24 PR 5 Pl.Housing Kit 14.3719.00 Washer 9 x 15 mm Kit P/N Description 60.1208.61 3.2 x 33 mm Spring 60.1212.24 VB8 Spare Parts Kit 9x1 pcs 1 LANDA SEA • 8.913-999.0 • Rev. 6/13...
  • Page 36 Authorized LANDA Dealer of the defect. Your Authorized LANDA Dealer will file a claim with Landa, who must subsequently verify the defect. In most cases, the part must be returned to LANDA freight prepaid with the claim. For warranty service on components warranted by other manufacturer’s, your Authorized LANDA Dealer can help you obtain warranty service through these manufacturers’...
