AudioCodes™ MP-100/104 Gateway
Quick Start Installation Guide
INTRODUCTION
This quick start guide contains information about how to install and configure the Audio-
Codes™ MP-100/104 Gateway. Although this guide covers both the MP-100 and MP-104
Gateways, the installation instructions apply to the MP-104. This gateway is the latest version
that is available through the Inter-Tel
refer to the latest version of the IP Devices Manual.
SYSTEM REQUIREMENTS
The following lists the system requirements for installing the AudioCodes MP-100/104 Gate-
way:
•
•
SYSTEM DATABASE PROGRAMMING
The IPRC firmware version determines how Axxess is programmed to support the gateways.
For details about system database programming, refer to the documents listed below.
If you are installing the gateway on a:
•
•
AUDIOCODES MP-100 GATEWAY INSTALLATION
For details about installing the AudioCodes MP-100, refer to the latest version of the IP
Devices Manual.
Document Part Number 835.2741-3
A946/3852A
AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide
Internet Protocol Resource Card (IPRC) firmware v1.3 or later
NOTE:
To support Session Initiation Protocol (SIP) on the AudioCodes MP-100/104
Gateway, v1.5 or later firmware is required.
®
Axxess
v7.0 or later
V1.x firmware IPRC, see the latest version of the IP Devices Manual.
V8.x firmware IPRC, see the Addendum to the v8.0 Installation and Maintenance Man-
ual.
®
CommSource™ division. For details about the MP-100,
© Inter-Tel, Inc. March 2004 printed in USA
March 2004
Page 1 of 17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AudioCodes MP-100
Summary of Contents for AudioCodes MP-100
- Page 1 V8.x firmware IPRC, see the Addendum to the v8.0 Installation and Maintenance Man- ual. AUDIOCODES MP-100 GATEWAY INSTALLATION For details about installing the AudioCodes MP-100, refer to the latest version of the IP Devices Manual. Document Part Number 835.2741-3 Page 1 of 17 A946/3852A ©...
-
Page 2: Restart Button
The AudioCodes MP-104 FXO gateway supports up to four loop start line (FXO - foreign exchange office) ports. Although the MP-104 is similar to the MP-100, each gateway uses a different switch type for configuring the device. The MP-100 uses DIP switches, and the MP-... - Page 3 The following steps outline the MP-104 installation. For details, refer to the pages shown in parentheses in each step. To install the MP-104: Unpack the box, and set up the MP-104 gateway device through the AudioCodes BootP/TFTP Server program (see below). Set up the MP-104 gateway device through the AudioCodes BootP/TFTP Server...
- Page 4 Detach and unzip the BootP and MP_104 zip files that are provided in the Inter-Tel AudioCodes CD (part no. 827.9920) into this folder. You may want to create a sub- folder for the BootP zip file within the same folder. The folder should look like the one shown below.
- Page 5 AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide March 2004 Copy the following files that you just unzipped and paste them into the BootP server folder (under C:\Program Files\AudioCodes). NOTE: The file names may be different depending on the version and date that the files are created.
- Page 6 Double-click bootp.exe to launch the AudioCodes BootP/TPTF Server program. The following screen appears. NOTE: Ensure the AudioCodes BootP/TFTP Server application is the only BootP server running. If another server, such as the IPRC, is running at the same time, it may cause problems with the download.
- Page 7 10. In the main BootP/TFTP Server screen, select Clients from the Services menu or click . The following dialog appears. The Client Configuration dialog allows the client (AudioCodes MP-104 gateway) to connect to the server application for code and con- figuration updates.
- Page 8 Make sure the Pause icon ( ) is not pressed in the main screen. If you have more than one AudioCodes MP-104 gateway, repeat steps 8 and 13. The BootP status in the BootP/TFTP Server should show “Client Found” and “100% OK”...
- Page 9 March 2004 Configuring the MP-104 Once the BootP Client is set up, configure the MP-104 in the AudioCodes Web administrator. To configure the MP-104: Open the Web browser and enter the IP address of your MP-104 gateway in the Address field.
- Page 10 AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide March 2004 Quick Setup: Configure the Quick Setup field, as described below. • IP Address: Enter the IP address of the MP-104. • Subnet Mask: Enter the subnet mask of the MP-104. •...
- Page 11 AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide March 2004 Protocol Management: Configure the Protocol Management field, as described below. — Control Protocol Type: Should be set to MGCP. — Call Agent IP: Should match the IPRC IP address. NOTE: If the MCGP gateway is behind a firewall or NAT, you must set the Call Agent IP.
- Page 12 AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide March 2004 Advanced Configuration: This page has the Network Settings, Channel Settings, Con- figuration File, Regional Settings, and Change Password fields. • Network Settings: Configure the Network Settings as described below. Auto Auto —...
- Page 13 Caller ID All settings, except the following, should remain the same as they are shown in the screen. For more details, refer to the AudioCodes MP-104 User’s Manual. — DTMF Transport Type: Should match the DTMF Encoding Setting on the IPRC Device page.
- Page 14 To upload the file to the gateway, click Browse to select the file that you just downloaded and then click Send file. To restore the settings, click Restore All Defaults. NOTE: Uploading an .ini file overwrites the existing settings in the AudioCodes Configuration Web page. After uploading, you must reprogram the AudioCodes Configuration (see page •...
- Page 15 AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide March 2004 • Change Password: Allows you to change the password. To apply the new pass- word, click Change Password. Status and Diagnostics: Allows you to see the Channel Status, Message Log, and Ver- sions of the MP-104.
- Page 16 AudioCodes™ MP-100/104 Gateway Quick Start Installation Guide March 2004 Software Update: Allows you to update configuration files using TFTP or HyperText Transfer Protocol (HTTP). • TFTP Download: Allows you to download the BOOT (.cmp) and/or .ini files. To download the files, enter the required information in the text boxes below and click RESET.
- Page 17 Then follow the instructions in the IP Devices Manual for the Quick Setup field and Circuit Configuration field. Make sure the connection(s) are active in the Circuit Status page. The AudioCodes MP-104 Gateway is now ready for connection to the CO. _____________________ ®...
